preface

---

Source location:caffe/examples/pycaffe/caffenet.py
The source code of this file is the Caffe implementation of the classic model AlexNet. Interested friends go to read the paper:ImageNet Classification with Deep Convolutional Neural Networks.

Source code interpretation

---

1. Import module

---

from __future__ import print_function
from caffe import layers as L, params as P, to_proto
from caffe.proto import caffe_pb2

2. Define the Layer function

---

include: Convolution Layer, Full Connected Layer, and Pooling Layer

2.1 Convolution Layer function

def conv_relu(bottom, ks, nout, stride=1, pad=0, group=1):
    conv = L.Convolution(bottom, kernel_size=ks, stride=stride,
                                num_output=nout, pad=pad, group=group)
    return conv, L.ReLU(conv, in_place=True)

Function input

• bottom - Input node (blob)name
• ks - Convolution kernel size (kernel size）
• nout - Output depth size (number output）
• stride - Convolution core sliding window distance
• pad - Add dimensions to the edges of the image, ie add a size around the image for a weekpadBlank pixel
• group - Separate data from the number of training piles

2. Call the Caffe volume base layer generation function

• conv = L.Convolution(bottom, kernel_size=ks, stride=stride,num_output=nout, pad=pad, group=group)

3. Return parameters

• conv - Convolution layer configuration
• L.ReLU(conv, in_place=True) - Data obtained by convolution of data via the ReLU activation function

2.2 Full Connected Layer

def fc_relu(bottom, nout):
    fc = L.InnerProduct(bottom, num_output=nout)
    return fc, L.ReLU(fc, in_place=True)

1. Call Caffe inner product function

• fc = L.InnerProduct(bottom, num_output=nout)

2. Return parameters

• fc, L.ReLU(fc, in_place=True) - Data after full join classification via ReLU function

2.3 Pooling Layer

def max_pool(bottom, ks, stride=1):
    return L.Pooling(bottom, pool=P.Pooling.MAX, kernel_size=ks, stride=stride)

Call Caffe pooling layer generation function

• L.Pooling)（）
• pool=P.Pooling.MAX - Select the MAX type for the pooling type, that is, take the maximum output in the template.

3. Define the network structure

---

data, label = L.Data(source=lmdb, backend=P.Data.LMDB, batch_size=batch_size, ntop=2,
        transform_param=dict(crop_size=227, mean_value=[104, 117, 123], mirror=True))

         # the net itself
    conv1, relu1 = conv_relu(data, 11, 96, stride=4)
    pool1 = max_pool(relu1, 3, stride=2)
    norm1 = L.LRN(pool1, local_size=5, alpha=1e-4, beta=0.75)
    conv2, relu2 = conv_relu(norm1, 5, 256, pad=2, group=2)
    pool2 = max_pool(relu2, 3, stride=2)
    norm2 = L.LRN(pool2, local_size=5, alpha=1e-4, beta=0.75)
    conv3, relu3 = conv_relu(norm2, 3, 384, pad=1)
    conv4, relu4 = conv_relu(relu3, 3, 384, pad=1, group=2)
    conv5, relu5 = conv_relu(relu4, 3, 256, pad=1, group=2)
    pool5 = max_pool(relu5, 3, stride=2)
    fc6, relu6 = fc_relu(pool5, 4096)
    drop6 = L.Dropout(relu6, in_place=True)
    fc7, relu7 = fc_relu(drop6, 4096)
    drop7 = L.Dropout(relu7, in_place=True)
    fc8 = L.InnerProduct(drop7, num_output=1000)
    loss = L.SoftmaxWithLoss(fc8, label)

    if include_acc:
        acc = L.Accuracy(fc8, label)
        return to_proto(loss, acc)
    else:
        return to_proto(loss)

Function input

• lmdb - file name
• batch_size - Number of samples entered per training
• include_acc - Accelerate?

2. Call Caffe data layer input function (Data)
L.Data(source=lmdb, backend=P.Data.LMDB, batch_size=batch_size, ntop=2, transform_param=dict(crop_size=227, mean_value=[104, 117, 123], mirror=True))

• backend - type of data
• ntop - outputblobNumber, because the data layer processes the data output data and label, so the value is 2
• transform_param - Processing a single image:crop_sizePicture crop size,mean_valueRGB images need to be subtracted (in order to better highlight features) andmirrorMirror processing.

Layer	Operation	Output
Data	crop_size:227, mean_value: [104, 117, 123], mirror: true	data: 227x227x3; label: 227x227x1
1	conv1 -> relu1 -> pool1 -> norm1	27x27x96
2	conv2 -> relu2 -> pool2 -> norm2	13x13x256
3	conv3 -> relu3	11x11x384
4	conv4 -> relu4	11x11x384
5	conv5 -> relu5 -> pool5	6x6x256
6	fc6 -> relu6 -> drop6	4096
7	fc7 -> relu7 -> drop7	4096
8	fc8 -> loss	1000

3. Network structure
This blog draws the AlexNet network structure diagram and data flow diagram to facilitate intuitive understanding of the network structure, which can be moved:Depth learning image classification model AlexNet interpretation
Layers 1-5 are convolutional layers, as shown in the following table:

Layer	Operation	Output
Data	crop_size:227, mean_value: [104, 117, 123], mirror: true	data: 227x227x3; label: 227x227x1
1	conv1 -> relu1 -> pool1 -> norm1	27x27x96
2	conv2 -> relu2 -> pool2 -> norm2	13x13x256
3	conv3 -> relu3	11x11x384
4	conv4 -> relu4	11x11x384
5	conv5 -> relu5 -> pool5	6x6x256
6	fc6 -> relu6 -> drop6	4096
7	fc7 -> relu7 -> drop7	4096
8	fc8 -> loss	1000

Take the layer 1 code as an example for analysis:

1. Layer 1 = Convolution layer (conv1+relu1) + Pooling layer (pool1) + Normalization (norm1)

(1). Layer 1 - Convolution layer (conv1+relu1)
Function: Extract local features, use ReLU as the activation function of CNN, and verify that the effect exceeds Sigmoid in deeper networks, and successfully solve the gradient dispersion problem of Sigmoid in the deep network. .
conv1, relu1 = conv_relu(data, 11, 96, stride=4)

• Data: data layer output data data
• Convolution kernel size: 11
• Output node depth: 96
• Sliding window distance: 4

(2). Layer 1 - pooling layer (pool1)
Function: Extract the maximum value to avoid the average pooling fuzzification effect. In AlexNet, the size of the concession is smaller than that of the pooled kernel, so that the output of the pooled layer overlaps and covers, which improves the richness of features.
pool1 = max_pool(relu1, 3, stride=2)

• Data: relu1
• Template core size: 3
• Sliding window distance: 2

(3). Layer 1 - Local Response Normalize (norm1)
Role: Create a competitive mechanism for the activity of local neurons, making the relatively large value of the response become relatively larger, and suppress other neurons with less feedback, enhancing the pan of the model Ability
norm1 = L.LRN(pool1, local_size=5, alpha=1e-4, beta=0.75)

• Data: pool1
• Value template size: 5
• alpha: 0.0001
• beta: 0.75

4. Output network structure file (.prototxt)

---

def make_net():
    with open('train.prototxt', 'w') as f:
        print(caffenet('/path/to/caffe-train-lmdb'), file=f)

    with open('test.prototxt', 'w') as f:
        print(caffenet('/path/to/caffe-val-lmdb', batch_size=50, include_acc=True), file=f)

5. Run

---

if __name__ == '__main__':
    make_net()

to sum up

---

Caffene.py is a good source code for Caffe. It can be combined with the original papers to deepen the understanding of the network structure and supplement the theoretical knowledge. The following is to build your own network structure based on this example form. The first step is to learn the most important step of deep learning, and write your own data type interface layer program.

the above.

Attached:

1. AlexNet Network Summary
2. Depth learning image classification model AlexNet interpretation

---
