After testing, the order of loading the ear package is loaded according to the order of the first letter of the package name. If the package call package occurs during the loading process, it is necessary to pay attention to the problem caused by the package name.

Question: What is the loading order of packages with different suffixes?

What is the loading order of the jar and war packages in the ear package?

What is the loading order of the class files and other files in the package?



to be continued. . . .





Answer to the question:



1. What is the loading order of the packages with different suffixes?

A: Turn:





The version mentioned below is jboss-4.2.3.GA

And suppose JBoss is installed at D:\Java\jboss-4.2.3.GA

JBoss supports a variety of formats to support the package, for example, we will see the suffix from the deploy directory as deployer, sar, war, rar, xml ... (later found that the format of JBoss deployment support, far not only these)

But what is the loading order of these different format applications? Or is there any law? With this question, I carefully looked at the information in the command line when JBoss started, and found two pieces of information:

1. The first application is the application or service with the suffix named deployer directory;

2. Each time an application with the same suffix (or an application under the directory) is completely loaded, it will load another suffix name.

After discovering these two points, I found some configuration files of JBoss, which were originally in D:\Java\jboss-4.2.3.GA\server\default\conf\xmdesc org.jboss.deployment.MainDeployer-xmbean.xml There is such a paragraph in the file:







<attribute access='read-write' setMethod='setEnhancedSuffixOrder' getMethod='getEnhancedSuffixOrder'>
      <description>Allows the override of the suffix order declared by subdeployers, using the syntax [order:]suffix
      </description>
      <name>EnhancedSuffixOrder</name>
      <type>[Ljava.lang.String;</type>
      <!--
         Statically set one or more enhanced suffix orders, independent of the value proposed by subdeployers.
         Some deployers may also allow the suffixes/orders to be set locally, so that's preferable too.
         For reference, this is the list of enhanced suffixes likely to be set by deployers (it may not
         be completely up-to-date, or there can be user-defined deployers).

         050:.deployer,050:-deployer.xml,100:.aop,100:-aop.xml,150:.sar,150:-service.xml,200:.  ,250:.rar,300:-ds.xml,350:.har,400:.jar,400:.ejb3,400:.par,500:.war,600:.wsr,650:.ear,700:.jar,750:.zip,800:.bsh,900:.last

         Until we resolve some startup issues, we'll setup some static enhanced suffix orders bellow
         and leave the rest of the suffixes contributed dynamically by registering deployers.
      -->
      <descriptors>
         <value value="250:.rar,300:-ds.xml,400:.jar,500:.war,550:.jse,650:.ear,800:.bsh"/>
      </descriptors>
   </attribute>



If we need to deploy a lot of applications under JBoss, and sometimes these applications need to have a sequential order, we can do it in two ways.
1. Deploy to different subdirectories according to actual needs
2, change the JBoss default loading order by modifying the following value



<descriptors>
     <value value="250:.rar,300:-ds.xml,400:.jar,500:.war,550:.jse,650:.ear,800:.bsh"/>
</descriptors>









Question 2: What is the loading order of the jar and war packages in the ear package?

A: After testing, the package loading order in the ear package is also loaded in the order set by the org.jboss.deployment.MainDeployer-xmbean.xml file.
