-BootStrap4 common grid system CSS notes

.row	Defines a row
.col	Average number of columns, up to row 12. Each column around each gap 15px
.to col- {1 12}	In all definitions the column width of the screen
.col- {sm \| md \| lg \| xl} - {1 12} to	In the definition of the screen of the column at the specified column width, sm: Screen> = 576px, md: Screen> = 720px, lg: Screen> = 960px, xl: Screen> = 1200px
to .offset- {1 11}	In all column offset screen
.offset- {sm \| md \| lg \| xl} - {1 11} to	Column offset at a specified screen
A Code: In all screen sizes, sharing three `<div class="row"> <div class="col bg-danger">1</div> <div class="col bg-dark">2</div> <div class="col bg-light">3</div> </div>` Code II: In all screen sizes, occupy 50% of the first column, the second column at 25%, the third column at 25% `<div class="row"> <div class="col-6 bg-primary">1</div> <div class="col bg-success">2</div> <div class="col bg-info">3</div> </div>` Code III: When the screen width> = 960 pixels, the first column at the 50%, 10% occupied by the second row, third column at 25%, the screen is less than 960 pixels, the width of each column at 100% `<div class="row"> <div class="col-lg-6 bg-primary">1</div> <div class="col-lg-3 bg-success">2</div> <div class="col-lg-3 bg-info">3</div> </div>` Code IV: column 1 at all screen sizes are shifted one column to the right width of the cell. An offset width of the cell column when a column to the right of the screen width 2> = 960 pixels `<div class="row"> <div class="col-lg-5 offset-1 bg-primary">1</div> <div class="col-lg-2 offset-lg-1 bg-success">2</div> <div class="col-lg-3 bg-info">3</div> </div>`
