LTP-linut test project. The ltp suite is a system test suite developed by the Linux Test Project. It develops a combination of tests based on the utilization statistics of system resources to provide sufficient pressure for the system.

Use the LTP test suite to test the Linux operating system for a long time, focusing on the workload related to the Linux user environment. It is not dedicated to proving defects. To



If you need to install the latest version or recompile, refer to the Quick Start section.

Quick Start

Download ltp package

Version page:https://github.com/linux-test-project/ltp/releases

wget https://github.com/linux-test-project/ltp/releases/download/20180515/ltp-full-20180515.tar.bz2 tar -xjvf ltp-full-20180515.tar.bz2

Install dependencies

CentOS 7.4

# Compile ltp use yum install make bison flex byacc autoconf automake m4 # Analyze performance data yum install deltarpm sysstat

Ubuntu (Kylin)

sudo apt install xxx # For testing purposes, if you can’t find the installation directly, you can go to https://launchpad.net/ubuntu/xenial/<architecture>/ search and download, for Feiteng server, the address ishttps://launchpad.net/ubuntu/xenial/arm64/ # But it is best to get it from the source configured by the server itself

Install ltp test cases

cd ltp/ # or the decompressed ltp directory with version number  ./configure make all make install /opt/ltp/runltplite.sh # After installing ltp in the /opt directory, you can quickly execute a script to verify the installation

ltp structure

ltp folder structure (only one level is shown)

[root@host2 ltp]# pwd /opt/ltp [root@host2 ltp]# tree -L 1 . ├── bin ├── IDcheck.sh # Check whether the system lacks the users and user groups required to execute the LTP test suite. If they are missing, create the required users and user groups for the LTP test suite. ├── runltp          ├── runltplite.sh # This script is used to test the LTP installation, and can also be used to test the sub-projects of the test suite. ├── runtest # Each file in this directory is a collection of commands for test cases to be executed, and each file is for different aspects of the test. ├── scenario_groups ├── share # Script usage instructions directory ├── testcases # This directory stores the source code of all test cases used in the LTP test suite. ├── testscripts # This directory stores executable test scripts, a collection of different aspects of test scripts. ├── ver_linux # This script is to obtain hardware, software, and environmental information. └── Version

[root@host2 ltp-full-20180515]# pwd /home/wenjie/ltp/ltp-full-20180515 [root@host2 ltp-full-20180515]# tree -L 1 -d . ├── doc # This directory is the location of the explanatory files and help documents. The contents of LTP and each tool are explained in detail in this directory. ├── include # The header file directory of the LTP test suite defines the data structure and function structure of the LTP itself. ├── lib # The library files needed by the LTP test suite when it runs, which define various functions of the LTP itself. ├── m4 ├── pan # This directory stores the test driver pan of the LTP test suite. ├── runtest ├── scenario_groups ├── scripts ├── testcases # This directory stores the source code of all test cases used in the LTP test suite. ├── testscripts # This directory stores executable test scripts, a collection of different aspects of test scripts. ├── tools └── utils



Test command

Initial test

The initial test directly uses the /opt/ltp/runltp script. By default, this script executes: file system stress test, hard disk I/O test, memory management stress test, IPC stress test, SCHED test, command function verification test, system call function verification test.

If no parameters are specified, then all use cases will be executed, and all execution processes will be printed to the screen without saving logs and results. It is recommended to add at least -p, -l parameters to save readable test results.

/opt/ltp/runltp -p -l result.yyyymmdd.log -f my_command_file /opt/ltp/runltp -p -l /tmp/resultlog.20111207 -d /tmp -o /tmp/ltpscreen.20111207 -t 24h

For parameter explanation, see http://ltp.sourceforge.net/documentation/how-to/ltp.php#_3.4

my_command_file should be placed under /opt/ltp/runtest, and the content format is as follows,

#Tag       Test case #--------------------------------------- mtest01     mtest01 -p 10 mmstress    mmstress -x 100 fork01      fork01 chdir01     symlink01 -T chdir01 #----------------------------------------

After the command is executed, if the absolute path of the log file is not specified, the log will be saved in the /opt/ltp/results directory. The output content is as follows,

Test Start Time: Mon Aug 20 11:41:40 2018 ----------------------------------------- Testcase                                           Result     Exit Value --------                                           ------     ---------- mtest01                                            FAIL       1 mmstress                                           PASS       0 fork01                                             PASS       0 chdir01                                            PASS       0   ----------------------------------------------- Total Tests: 4 Total Skipped Tests: 0 Total Failures: 1 Kernel Version: 3.10.0-693.el7.1.x86_64 Machine Architecture: x86_64 Hostname: host1



pressure test

Execute the ltpstress.sh script in testscripts for stress testing. The script runs similar test cases in parallel and different test cases serially. By default, this script executes: NFS stress test, memory management stress test, file system stress test, math (floating point) test, multi-threaded stress test, hard disk I/O test, IPC (pipeio, semaphore) test, system call function Verification test, network stress test.

cd /opt/ltp/testscripts sudo ./ltpstress.sh -m 35 -S -t 1  # If you directly execute the test script in the source package, you need to execute PATH=$PATH:$PWD:<LTP_ROOT>/lib/ before running, and add <LTP_ROOT>/lib and <LTP_ROOT>/testscripts to the PATH sudo ./ltpstress.sh -d /tmp/sardata -l /tmp/ltpstress.log -I /tmp/iofile -i 5 -m 128 -t 24 -S sudo ./ltpstress.sh -p -S -t 1 -b /dev/sdd -B xfs -m 128

-l: Record test results to /tmp/ltpstress.log (lowercase L)

-I: Record the result of "iostat" to iofile, the default is /tmp/ltpstress.iostat (uppercase i)

-i: Specify the sar or top snapshot interval, the default is 10 seconds

-m: Specify the minimum memory usage, the default is: RAM + 1/2 swap

-n: Do not stress test the network

-S: Use sar to capture data

-T: Use the top tool modified by LTP to capture data

-T: Specify the test time # The -t parameter of the ltpstress.sh script, only supports the integer "hour".

-b: Part of the test requires a disk without mount. If not specified, the script will create a loop device for testing

-B: description of the file system of the disk specified by -b

Note: If you do not specify -m, the pressure will be greater, and resource consumption may burst. Be sure to bring the -m parameter.



Correspondence of file structure related to stress test script:

• Ltpstress.sh in testscripts
• Stress.part1, stress.part2, stress.part3 under the runtest directory (test set configuration files)
• Run in the background pan
• Execute each test case in Testcase finally

The combination of test cases can be adjusted by modifying the stress.part<n> file under runtest.



Test data analysis

By default, the test results are placed in /tmp
ltpstress.log: Record related log information, mainly whether the test passes or fails (pass or fail)
ltpstress.data: the day file recorded by the sar tool, including cpu, memory, i/o, etc.
ltpstress.<xxx>.output1: corresponding to stress.part1, some output information of the test command
ltpstress.<xxx>.output2: corresponding to stress.part2
ltpstress.<xxx>.output3: corresponding to stress.part3



ltpstress.sh supports -S to call the sar command to record server performance data. If -S is not specified, the top command customized by ltp will be used to record performance data.

sar -u -f ltpstress.data # cpu average utilization rate sar -r -f ltpstress.data # memory average usage rate sar -b -f ltpstress.data # IO transfer rate sar -d -f ltpstress.data # Activity information of each disk

Extract the wrong use cases, and then analyze the reasons for each wrong use case.

grep FAIL ltpstress.xxx.output* | sort | uniq >failcase.txt





Related test collection

• runtests/net.nfs: contains test collections of NFS v2, v3, and v4, which need to be enabled and configured for nfs and portmap services. Excuting an order:

  /opt/ltp/runltp -p -l result.yyyymmdd.log -f net.nfs

• runtests/network_commands: contains a collection of tests for ftp and ssh.
• runtests/scsi_debug.part1: corresponding script testscripts/ltp-scsi_debug.sh.



In the downloaded ltp package, there is a separate disktest directory under testcases/kernal/io/. Contains the disktest script, which can be executed. The document is attached.disktest_manual.html



Reference documents:

http://ltp.sourceforge.net/documentation/how-to/ltp.php#_1



https://github.com/linux-test-project/ltp
