LTP and Stream Performance Test Tools

LTP tool installation and use

http://sourceforge.net/projects/ltp/files/LTP Source/

http://ltp.sourceforge.net/

1, install compilation

​ tar jxvf ltp-full-20150420.tar.bz2

​ cd ltp-full-20150420/

​ ./configure

​ Make && make install

​ cd /opt/ltp/

./Runltp -f commands (Test regular command)

./Runltp -f admin_tools (Test whether the common management tool is normal and stable)

./Runltp -f fcntl-locktests (Test if the NFS network file system lock is stable)

./Runltp -f admin_tools (Test whether the common management tool is normal and stable)

./Runltp -f dio (test is normal if the direct IO is stable)

./Runltp -f dma_thread_diotest (Test Direct Memory Access Thread Direct IO is normal)

./Runltp -f fcntl-locktests (Test if the NFS network file system lock is stable)

./Runltp -f filecaps (Test if FileCaps is normal)

Prefabrication: Plus a line in the /etc/sysctl.conf file:

CONFIG_SECURITY_FILE_CAPABILITIES = Y Restart the computer

./RunLTP -F fs (whether the test file system is normal)

./Runltp -f fs_bind (Test if fs_bind is normal)

./RUNLTP -F FS_EXT4 (Test if fs_ext4 is normal)

./Runltp -f fs_perms_simple (simple test file system permission)

./Runltp -f fs_readonly (Test file system read only)

./Runltp -f fsx (pressure testing file system)

./Runltp -f hyperthreading (CPU Hyperith Technology Test)

./Rmnltp -f io (asynchronous IO test)

./RunLTP -F IO_CD (Pressure Test for CD CD-ROM) Prefabrication: Put the CD into the optical drive

					-T: Time to specify the test

​     				 -t 60s = 60 seconds

  				    -t 45m = 45 minutes

   				   -t 24h = 24 hours

   				   -t 2d = 2 days

./Runltp -f lvm.part1 (Test file system MSDOS, Reiserfs, EXT2, NFS, RAM Disk, minix)

./Runltp -f math (math library test)

./Runltp -f nfs (NFS Network File System Test) Prefab Condition: Configuring NFS File System Services in this unit

./Runltp -f pipes (pressure testing pipeline)

./Runltp -f syscalls (test kernel system call)

./Runltp -f syscalls-ipc (Interprocess communication test)

./Runltp -f can (Test the stability of the area network of the controller)

./Runltp -f connectionors (Test the functionality and stability of NetLink Connector)

./Runltp -f ipv6 (the basic network function in the IPv6 environment)

./Runltp -f ipv6_lib (IPv6 Environmental Network Development Shared Library) Prefab Conditions: Kernel Support IPv6

./Runltp -f multicast (Stability of testing multicast)

Prefabrication:

(1) Set environment variables export rhost = <multicast target address>

(2) /Root/.rhosts ,/home/user/.rhosts Add Content: Multicast Target Host Address, Multicast Target Host User, how many multicast target hosts write how many strips.

./Runltp -f network_commands (Stability of FTP and SSH) Prefab Condition: Open FTP and SSH

./Runltp -f network_stress.whole (Pressure test of networks) (2) Services running on the server: SSH DNS HTTP FTP

	./runltp -f nptl (Test the stability of the local POSIX thread library) Prefault: kernel support POSIX local line library

./RunLTP -F Pty (Test Virtual Terminal Stability) Prefab Condition: Core Support VT Console

./Runltp -f quickhit (stability of test system call)

./Runltp -f rpc and ./runltp -f rpc_test (Test Remote Procedure Call Stability Prefab Condition: Kernel Supports Remote Process

... / RUNLTP -F Modules (test kernel module)

Initial test

​ ./runltp -p -l /tmp/resultlog.20180421 -d /tmp/ -o /tmp/ltpscreen.20180421 -t 1h

Or./runalltests.sh

		-p: Artificial specified log format, guarantee log for readable format
      	        -L: Record the file of the test log
      	        -d: Specify a temporary storage directory, defaults to / TMP
                 -o: Direct print test output to /tmp/ltpscreen.20180421
			 -T: Time to specify the test
             -t 60s = 60 seconds
             -t 45m = 45 minutes
             -t 24h = 24 hours
             -t 2d  = 2 days

Vim /TMP/Resultlog.20180421 View

Pressure test: LTP-full-20150420.tar.bz2 Unshard in this package may be environmental reasons.

cd /opt/ltp/testscripts/

Yum Install GCC-C ++ LibSTDC + ± Devel first installed dependence

Yum install -y sysstat installed this

./ltpstress.sh -d /tmp/ltpstress.data -l /tmp/ltpstress.log -I /tmp/ltpstress.iostat -i 5 -m 128 -t 1 –S

					 -d: Specify SAR or TOP record file, default / TMP/LTPSTRESS.DATA
                                           -l: Record test results to /tmp/ltpstress.log
                                             -I: Record "iostat" results to IOFILE, default is /TMP/ltpstress.ioStat
                                             -i: Specify SAR or TOP snapshot time interval, default is 10 seconds
                                           -m: Specify the smallest memory usage, default: RAM + 1/2 SWAP
                                           -n: Do not pressure testing network
                                           -S: Capture data with SAR
                                           -T: Capture data using the TOP tool modified by LTP
                                           -t: Specify test time, default is an hour

There will be a lot of LTPSTress files in CD / TMP /.

SAR -U -F LTPSTRESS.DATA test CPU average usage

SAR -R-F ltpstress.data Memory average usage

---

Performance Test Tools Stream

https://pan.baidu.com/s/15ds1trgkcvg6ymgqjmly4Q pickup code: Kryj

tar xf stream.tar

1, single-thread compilation

gcc -O -mcmodel=medium -DSTREAM_ARRAY_SIZE=100000000 -mcmodel=large -DNTIME=20 stream.c -o stream.o

​

./stream.o execution

​

2, multi-threaded compilation

gcc -O -mcmodel=medium -fopenmp -DSTREAM_ARRAY_SIZE=100000000 -mcmodel=large -DNTIME=20 stream.c -o stream.o

[Outer chain picture "failed, the source station may have an anti-theft chain mechanism, it is recommended to save the picture directly upload (IMG-NBOOFBOR-1620028675088) (C: \ users \ Dell \ AppData \ Roaming \ Typora \ Typora-user-images \ IMAGE-20210503152344877.png)]

./stream.o execution

e -DNTIME=20 stream.c -o stream.o

[ ... (img-nboofbor-1620028675088)]

./stream.o execution

[ ... (img-pueglbem-1620028675089)]

[ ... (IMG-1BOY2CCE-1620028675090)]
