UDP communication between MATLAB / SIMULINK with labview
tags: data Software, and simulation platform
Article Directory
0. EDITORIAL
UDP protocol is relatively rigid SIMULINK, and the data type is generally *** DOUBLE *** SIMULINK data transfer. And on LABVIEW UDP receiving end receives the data string *** *** generally, it is necessary to write additional decoding Packager to achieve communication between the two.
1. MATLAB / SIMULINK end
Send 1.1
Relatively simple transmission, shown in FIG.
1.2 Receiving
Receiving end
2. LABVIEW end transceiver
2.1 reception
Note that, labview received little endian data need to be changed before they receive the correct
Send 2.2
Similarly, when transmitting data can be selected labview little endian, the transmitting side as follows
