Double-click the Simulink module call custom MATLAB scripts

- 1. Module set the callback function
- 2. Open the module by script

Reference: http://blog.sina.com.cn/s/blog_627927570102wq0d.html

1. Module set the callback function

The script used by the callback function is placed within the search path;

2. Open the module by script

open_system([bdroot,'/aaa'])  % Module path, double-click Open Effect` to insert the code for the code here`

Or use the mouse to double-click the module, perform the set script, as follows:

Xiao Gong is gone! O (∩_∩) o Haha ~
