It is well known that SpringBoot can use timed tasks through @Scheduled, but we need to dynamically export reports regularly. What can we do? Of course, there are many task schedulers on the market that are also good. This article mainly teaches you to use the Nacos configuration center Realize dynamic task scheduling with SpringBoot.
Not much to say, the code is here.

public interface AbstractDynamicSchedule extends Runnable {

    /**
           * mission name
           * @return returns the name of the execution task for logging
     */
    String taskName();

    /**
           * The cron expression yaml key of the task
     * @return yaml key
     */
    String cronKey();

}

The strategy mode is adopted to implement our main body. Dynamic creation of tasks is definitely not Runnable. From the source code of Scheduled, we can understand that a new timing task can be created through .schedule (Runnable, Cron), and a timing can be cancelled through .cancel Task Then we can start from here to make changes.

import cn.timesgroup.market.backend.common.schedule.AbstractDynamicSchedule;
import com.alibaba.nacos.spring.context.event.config.NacosConfigReceivedEvent;
import com.alibaba.nacos.spring.util.parse.DefaultYamlConfigParse;
import com.google.common.collect.Lists;
import lombok.extern.slf4j.Slf4j;
import org.apache.commons.lang3.StringUtils;
import org.springframework.context.ApplicationContext;
import org.springframework.context.ApplicationListener;
import org.springframework.scheduling.annotation.SchedulingConfigurer;
import org.springframework.scheduling.concurrent.ConcurrentTaskScheduler;
import org.springframework.scheduling.config.CronTask;
import org.springframework.scheduling.config.ScheduledTaskRegistrar;
import org.springframework.stereotype.Component;

import javax.annotation.Resource;
import java.util.*;
import java.util.concurrent.ConcurrentHashMap;
import java.util.concurrent.ScheduledFuture;

@Component
@Slf4j
public class NacosCronDataIdChangeListener implements ApplicationListener<NacosConfigReceivedEvent>, SchedulingConfigurer {

    private static final String CRON_YAML = "application-dynamic-schedule.yml";

    private ScheduledTaskRegistrar taskRegistrar;
	//Store the created timed task, if it is modified, it is used to delete the previous timed task
    private static final ConcurrentHashMap<String, ScheduledFuture<?>> SCHEDULED_FUTURES = new ConcurrentHashMap<>();
    private static final ConcurrentHashMap<String, CronTask> CRON_TASKS = new ConcurrentHashMap<>();
    @Resource
    private ApplicationContext applicationContext;
    /**
           * Store all dynamic timing task processing classes
     */
    @Resource
    private Map<String, AbstractDynamicSchedule> scheduleMap;

    @Override
    public void onApplicationEvent(NacosConfigReceivedEvent event) {

        if (!CRON_YAML.equals(event.getDataId())) {
            return;
        }

        DefaultYamlConfigParse parse = new DefaultYamlConfigParse();
        Properties properties = parse.parse(event.getContent());

        Collection<AbstractDynamicSchedule> editCronScheduleMap = Lists.newArrayList();

        // Compare each configuration
        scheduleMap.keySet().forEach(schedule -> {

            AbstractDynamicSchedule bean = (AbstractDynamicSchedule) applicationContext.getBean(schedule);
            String cronKey = bean.cronKey();

            String oldCronValue = CRON_TASKS.get(cronKey).getExpression();
            String newCronValue = properties.getProperty(cronKey);

            if (Objects.equals(oldCronValue, newCronValue)) {
                return;
            }

            // has changed
            editCronScheduleMap.add(scheduleMap.get(schedule));
        });

        this.refreshTasks(editCronScheduleMap);
    }

    public void refreshTasks(Collection<AbstractDynamicSchedule> tasks) {

        tasks.forEach(schedule -> {

            String cronKey = schedule.cronKey();

            // Cancel the deleted strategy task
            if ("-".equals(cronKey) || StringUtils.isBlank(cronKey)) {
                SCHEDULED_FUTURES.get(cronKey).cancel(false);
            }

            String cronNewValue = applicationContext.getEnvironment().getProperty(cronKey);

            // There is no change in the timing task
            if (
                    (SCHEDULED_FUTURES.containsKey(cronKey)
                            && CRON_TASKS.get(cronKey).getExpression().equals(cronNewValue))
                    || StringUtils.isBlank(cronNewValue)
            ) {
                return;
            }

            boolean isUpdate = false;
            // If the strategy execution time has changed, cancel the task of the current strategy
            if (SCHEDULED_FUTURES.containsKey(cronKey)) {
                SCHEDULED_FUTURES.get(cronKey).cancel(false);
                SCHEDULED_FUTURES.remove(cronKey);
                CRON_TASKS.remove(cronKey);
                isUpdate = true;
            }

            CronTask task = new CronTask(schedule, cronNewValue);
            CRON_TASKS.put(cronKey, task);
            ScheduledFuture<?> future = Optional.ofNullable(taskRegistrar.getScheduler())
                    .orElse(new ConcurrentTaskScheduler()).schedule(task.getRunnable(), task.getTrigger());
            SCHEDULED_FUTURES.put(cronKey, future);

            if (isUpdate) {
                log.info("Timing task modification, taskName={}, cronKey={}, taskNewCron={}",
                        schedule.taskName(), cronKey, cronNewValue);
            } else {
                log.info("Added scheduled tasks, taskName={}, cronKey={}, taskCron={}",
                        schedule.taskName(), cronKey, cronNewValue);
            }

        });
    }

    @Override
    public void configureTasks(ScheduledTaskRegistrar taskRegistrar) {

        this.taskRegistrar = taskRegistrar;

        this.refreshTasks(scheduleMap.values());
    }
}

Here you can listen to the NacosConfigReceivedEvent event to know when the configuration file has changed. When changing, we can also match and change the corresponding timing tasks. Here we use cronKey to match. Of course, don’t forget to monitor the configuration change meeting After listening to all here, we only pay attention to the ones that should be concerned.
And the SchedulingConfigurer is only used to get the required ScheduledTaskRegistrar so that the corresponding monitoring can be performed

Now we can test it

@Component
@Slf4j
public class TestSchedule1 implements AbstractDynamicSchedule {


    @Override
    public String taskName() {
        return "Test Timing";
    }

    @Override
    public String cronKey() {
        return "test-dynamic-schedule";
    }

    @Override
    public void run() {
        log.debug(new Date() + "----1");
    }
}

Yaml file:

test-dynamic-schedule: 0 * * * * ?

Run Info:

This concludes this article.
