AWTK supports Rive animation
tags: ZLG Open Source GUI AWTK AWTK Rive
awtk-widget-rive
Rive It is a super powerful animation format and a supporting tool.rive player The control is based onrive-cpp RealizeRive player.
Prepare
- Get AWTK and compile
git clone https://github.com/zlgopen/awtk.git
cd awtk; scons; cd -
- Get the AWTK-Widget-Rive and compile
git clone https://github.com/zlgopen/awtk-widget-rive
cd awtk-widget-rive
git clone https://github.com/rive-app/rive-cpp src/rive-cpp
scons
run
-
- Generate the resource of sample code
python scripts/update_res.py all
You can also use Designer to open the project, then click the "Package" button to generate;
If the resource is modified, you will need to regenerate resources.
If the PIL is not installed, performing the above script may have the following error:
Traceback (most recent call last):
...
ModuleNotFoundError: No module named 'PIL'
Please install PIP:
pip install Pillow
- Compile
- Compile PC version
scons
- Compile Linux FB version
scons LINUX_FB=true
Full compilation option, please refer toCompile option
- run
./bin/demo
Documentation
- Method created in XML
<rive x="c" y="m" w="600" h="400" name="rive" url="heart.riv"/>
Question
- Please use Cairo's Backen for VGCANVAS to get a full-featured demo, other backend may have potential problems due to non-CLIP PATH and multiple STOP gradients.
Modify AWTK / AWTK_CONFIG.PY and recompile:
VGCANVAS='CAIRO'
