ndgrid and meshgrid functions-Matlab

tags: Matlab

ndgridFunction andmeshgridThe function is similar, but the former supports from 1 to n dimensions, while the latter is only limited to 2 and 3 dimensions. In 2D and 3D, the coordinate output of the two functions is the same. The difference lies in the shape of the output array. For grid vectors x1gv, x2gv, x3gv, the lengths are M, N, and P respectively.ndgrid（x1gv, x2gv）The function outputs an array of MXN, andmeshgrid（x1gv, x2gv）Output an N*M array, similarly,ndgrid（x1gv, x2gv, x3gv）The function outputs an array of M*N*P, andmeshgrid（x1gv, x2gv, x3gv）Output an array of N*M*P .

The following example illustrates

[cpp] view plain copy
  1. x1gv =  [1 2];
  2. x2gv =  [4 5 6];
  3. x3gv =  [4 5 6 7];
  4. a = ndgrid(x1gv,x2gv,x3gv)
  5. b = meshgrid(x1gv,x2gv,x3gv)

Result output

[cpp] view plain copy
  1. a(:,:,1) =
  2.      1     1     1
  3.      2     2     2
  4.
  5. a(:,:,2) =
  6.      1     1     1
  7.      2     2     2
  8.
  9. a(:,:,3) =
  10.      1     1     1
  11.      2     2     2
  12.
  13. a(:,:,4) =
  14.      1     1     1
  15.      2     2     2
[cpp] view plain copy
  1. b(:,:,1) =
  2.      1     2
  3.      1     2
  4.      1     2
  5.
  6. b(:,:,2) =
  7.      1     2
  8.      1     2
  9.      1     2
  10.
  11. b(:,:,3) =
  12.      1     2
  13.      1     2
  14.      1     2
  15.
  16. b(:,:,4) =
  17.      1     2
  18.      1     2
  19.      1     2


For example, the dimensions of x1gv, x2gv, and x3gv are 2, 3, and 4 respectively. After executing the two functions, a = ndgrid(x1gv,x2gv,x3gv), the dimensions of the output a is 2x3x4, and b = meshgrid(x1gv,x2gv,x3gv), the output dimension is 3x2x4.


The following explains the ndgrid() function in detail

 [X1,X2,X3,...] = ndgrid(x1gv,x2gv,x3gv,...), copy the values ​​of x1gv,x2gv,x3gv,... to generate a rectangular grid coordinate (X1,X2,X3,...). The element of the i-th dimension of the output array Xi is copied from the grid vector xigv. For example, the grid vector x1gv forms the rows of X1, the grid vector x2gv forms the columns of X2, and so on...

The above may be more convoluted, for a simple example,

[cpp] view plain copy
  1. x1gv =1:.1:2;
  2. x2gv =4:.2:5;
  3. [a b]= ndgrid(x1gv,x2gv)
among them,

x1gv = [1 1.1 1.2 1.3 1.4 1.4 1.5 1.6 1.7 1.8 1.8 1.9 2], dimension is 1*11, length is 11, x2gv = [4 4.2 4.4 4.6 4.8 5], dimension The number is 1*6 and the length is 6, then, the rows of the output a are copied from the elements of x1gv, and the columns of the output b are also copied from the elements of x2gv.

The output result is as follows: As mentioned above, the dimension of the output array should be 11*6. Compare the contents of a and b with x1gv and x2gv, and you can understand the above Mouth place.

[cpp] view plain copy
  1. a =
  2.     1.0000    1.0000    1.0000    1.0000    1.0000    1.0000
  3.     1.1000    1.1000    1.1000    1.1000    1.1000    1.1000
  4.     1.2000    1.2000    1.2000    1.2000    1.2000    1.2000
  5.     1.3000    1.3000    1.3000    1.3000    1.3000    1.3000
  6.     1.4000    1.4000    1.4000    1.4000    1.4000    1.4000
  7.     1.5000    1.5000    1.5000    1.5000    1.5000    1.5000
  8.     1.6000    1.6000    1.6000    1.6000    1.6000    1.6000
  9.     1.7000    1.7000    1.7000    1.7000    1.7000    1.7000
  10.     1.8000    1.8000    1.8000    1.8000    1.8000    1.8000
  11.     1.9000    1.9000    1.9000    1.9000    1.9000    1.9000
  12.     2.0000    2.0000    2.0000    2.0000    2.0000    2.0000
  13.
  14. b =
  15.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  16.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  17.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  18.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  19.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  20.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  21.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  22.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  23.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  24.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000
  25.     4.0000    4.2000    4.4000    4.6000    4.8000    5.0000

Finally, the dimension of the output array is determined by the number of output variables, which is determined byndgrid（……）Determined by the number of output lists on the right side of the function. This sentence means that if the number of outputs is 1, then the dimension is N*1, and N is the length of the grid vector, if the number of outputs is 2, then the dimension of each is N*N.

[cpp] view plain copy
  1. x1gv =1:.1:2;
  2. [a]= ndgrid(x1gv)

[cpp] view plain copy
  1. a =
  2.     1.0000
  3.     1.1000
  4.     1.2000
  5.     1.3000
  6.     1.4000
  7.     1.5000
  8.     1.6000
  9.     1.7000
  10.     1.8000
  11.     1.9000
  12.     2.0000

[cpp] view plain copy
  1. x1gv =1:.1:2;
  2. [a b]= ndgrid(x1gv)









 [cpp] view plain copy











  1.  a =
    2.

  2.    Columns 1 through 9
    3.

  3.      1.0000    1.0000    1.0000    1.0000    1.0000    1.0000    1.0000    1.0000    1.0000
    4.

  4.      1.1000    1.1000    1.1000    1.1000    1.1000    1.1000    1.1000    1.1000    1.1000
    5.

  5.      1.2000    1.2000    1.2000    1.2000    1.2000    1.2000    1.2000    1.2000    1.2000
    6.

  6.      1.3000    1.3000    1.3000    1.3000    1.3000    1.3000    1.3000    1.3000    1.3000
    7.

  7.      1.4000    1.4000    1.4000    1.4000    1.4000    1.4000    1.4000    1.4000    1.4000
    8.

  8.      1.5000    1.5000    1.5000    1.5000    1.5000    1.5000    1.5000    1.5000    1.5000
    9.

  9.      1.6000    1.6000    1.6000    1.6000    1.6000    1.6000    1.6000    1.6000    1.6000
    10.

  10.      1.7000    1.7000    1.7000    1.7000    1.7000    1.7000    1.7000    1.7000    1.7000
    11.

  11.      1.8000    1.8000    1.8000    1.8000    1.8000    1.8000    1.8000    1.8000    1.8000
    12.

  12.      1.9000    1.9000    1.9000    1.9000    1.9000    1.9000    1.9000    1.9000    1.9000
    13.

  13.      2.0000    2.0000    2.0000    2.0000    2.0000    2.0000    2.0000    2.0000    2.0000
    14.

  14.
    15.

  15.    Columns 10 through 11
    16.

  16.      1.0000    1.0000
    17.

  17.      1.1000    1.1000
    18.

  18.      1.2000    1.2000
    19.

  19.      1.3000    1.3000
    20.

  20.      1.4000    1.4000
    21.

  21.      1.5000    1.5000
    22.

  22.      1.6000    1.6000
    23.

  23.      1.7000    1.7000
    24.

  24.      1.8000    1.8000
    25.

  25.      1.9000    1.9000
    26.

  26.      2.0000    2.0000
    27.

  27.
    28.

  28.  b =
    29.

  29.    Columns 1 through 9
    30.

  30.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    31.

  31.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    32.

  32.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    33.

  33.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    34.

  34.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    35.

  35.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    36.

  36.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    37.

  37.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    38.

  38.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    39.

  39.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    40.

  40.      1.0000    1.1000    1.2000    1.3000    1.4000    1.5000    1.6000    1.7000    1.8000
    41.

  41.
    42.

  42.    Columns 10 through 11
    43.

  43.      1.9000    2.0000
    44.

  44.      1.9000    2.0000
    45.

  45.      1.9000    2.0000
    46.

  46.      1.9000    2.0000
    47.

  47.      1.9000    2.0000
    48.

  48.      1.9000    2.0000
    49.

  49.      1.9000    2.0000
    50.

  50.      1.9000    2.0000
    51.

  51.      1.9000    2.0000
    52.

  52.      1.9000    2.0000
    53.

  53.      1.9000    2.0000
    54.













 gives a dazzling drawing method









 [cpp] view plain copy











  1.  [x1,x2,x3] = ndgrid(-2:.2:2, -2:.25:2, -2:.16:2);
    2.

  2.  z = x2 .* exp(-x1.^2 - x2.^2 - x3.^2);
    3.

  3.  slice(x2,x1,x3,z,[-1.2 .8 2],2,[-2 -.2]);
    4.

























 The above explanation may not be very clear, you can refer to the help file of matlab for details


 Attach the link:http://cn.mathworks.com/help/matlab/ref/ndgrid.html
