Although Delaunay triangulation algorithm can be implemented mesh surface reconstruction, but its application is mainly split in two-dimensional, three-dimensional space having problems in mesh generation. Because the three-dimensional point cloud surface reconstruction, Delaunay condition is not satisfied, not only on the determination of the maximum and minimum angle of diagonal switching criterion is not established, and the circumscribed circle Delaunay triangulation-based criterion can not guarantee the quality of the mesh.

VTKSurfaceReconstructionFilter is to achieve an implicit method for surface reconstruction, i.e. seen as a curved surface contour signed distance function from the inside and outside surfaces of opposite sign worth, and the zero set is also desired curved surface. This method requires meshing point cloud data, and then estimating the direction of a tangent plane for each point and each point to the nearest tangent plane approximate distance from the surface. Thus the volume data to obtain a symbol distance. In this way, we can use VTKContourFilter to extract zero isosurface to obtain the corresponding grid.

Face using point cloud data grid face surface reconstruction examples are as follows:

[cpp]  view plain  copy

1. #include <vtkAutoInit.h>
2. VTK_MODULE_INIT(vtkRenderingOpenGL);
3. VTK_MODULE_INIT(vtkRenderingFreeType);
4. VTK_MODULE_INIT(vtkInteractionStyle);
5.
6. #include <vtkSmartPointer.h>
7. #include <vtkPolyDataReader.h>
8. #include <vtkPolyData.h>
9. #include <vtkSurfaceReconstructionFilter.h>
10. #include <vtkContourFilter.h>
11. #include <vtkVertexGlyphFilter.h>
12. #include <vtkPolyDataMapper.h>
13. #include <vtkActor.h>
14. #include <vtkRenderer.h>
15. #include <vtkCamera.h>
16. #include <vtkRenderWindow.h>
17. #include <vtkRenderWindowInteractor.h>
18. #include <vtkProperty.h>
19.
20. int main()
21. {
22.     vtkSmartPointer<vtkPolyDataReader> reader =
23.         vtkSmartPointer<vtkPolyDataReader>::New();
24.     reader->SetFileName("fran_cut.vtk");
25.     reader->Update();
26.
27.     vtkSmartPointer<vtkPolyData> points =
28.         vtkSmartPointer<vtkPolyData>::New();
29.     points->SetPoints(reader->GetOutput()->GetPoints()); // get the mesh geometry data: set of points
30.
31.     vtkSmartPointer<vtkSurfaceReconstructionFilter> surf =
32.         vtkSmartPointer<vtkSurfaceReconstructionFilter>::New();
33.     surf->SetInputData(points);
34.     surf->SetNeighborhoodSize(20);
35.     surf->SetSampleSpacing(0.005);
36.     surf->Update();
37.
38.     vtkSmartPointer<vtkContourFilter> contour =
39.         vtkSmartPointer<vtkContourFilter>::New();
40.     contour->SetInputConnection(surf->GetOutputPort());
41.     contour->SetValue(0, 0.0);
42.     contour->Update();
43.     //////////////////////////////////////////////////
44.     vtkSmartPointer <vtkVertexGlyphFilter> vertexGlyphFilter =
45.         vtkSmartPointer<vtkVertexGlyphFilter>::New();
46.     vertexGlyphFilter->AddInputData(points);
47.     vertexGlyphFilter->Update();
48.     vtkSmartPointer<vtkPolyDataMapper> pointMapper =
49.         vtkSmartPointer<vtkPolyDataMapper>::New();
50.     pointMapper->SetInputData(vertexGlyphFilter->GetOutput());
51.     pointMapper->ScalarVisibilityOff();
52.
53.     vtkSmartPointer<vtkActor> pointActor =
54.         vtkSmartPointer<vtkActor>::New();
55.     pointActor->SetMapper(pointMapper);
56.     pointActor->GetProperty()->SetColor(1, 0, 0);
57.     pointActor->GetProperty()->SetPointSize(4);
58.
59.     vtkSmartPointer<vtkPolyDataMapper> contourMapper =
60.         vtkSmartPointer<vtkPolyDataMapper>::New();
61.     contourMapper->SetInputData(contour->GetOutput());
62.     vtkSmartPointer<vtkActor> contourActor =
63.         vtkSmartPointer<vtkActor>::New();
64.     contourActor->SetMapper(contourMapper);
65.     ///////////////
66.     double pointView[4] = { 0, 0, 0.5, 1 };
67.     double contourView[4] = { 0.5, 0, 1, 1 };
68.
69.     vtkSmartPointer<vtkRenderer> pointRender =
70.         vtkSmartPointer<vtkRenderer>::New();
71.     pointRender->AddActor(pointActor);
72.     pointRender->SetViewport(pointView);
73.     pointRender->SetBackground(1, 1, 1);
74.
75.     vtkSmartPointer<vtkRenderer> contourRender =
76.         vtkSmartPointer<vtkRenderer>::New();
77.     contourRender->AddActor(contourActor);
78.     contourRender->SetViewport(contourView);
79.     contourRender->SetBackground(0, 1, 0);
80.
81.     pointRender->GetActiveCamera()->SetPosition(0, -1, 0);
82.     pointRender->GetActiveCamera()->SetFocalPoint(0, 0, 0);
83.     pointRender->GetActiveCamera()->SetViewUp(0,0,1);
84.     pointRender->GetActiveCamera()->Azimuth(30);
85.     pointRender->GetActiveCamera()->Elevation(30);
86.     pointRender->ResetCamera();
87.     contourRender->SetActiveCamera(pointRender->GetActiveCamera());
88.
89.     vtkSmartPointer<vtkRenderWindow> rw =
90.         vtkSmartPointer<vtkRenderWindow>::New();
91.     rw->AddRenderer(pointRender);
92.     rw->AddRenderer(contourRender);
93.     rw->SetSize(640, 320);
94.     rw->SetWindowName("3D Surface Reconstruction ");
95.     rw->Render();
96.
97.     vtkSmartPointer<vtkRenderWindowInteractor> rwi =
98.         vtkSmartPointer<vtkRenderWindowInteractor>::New();
99.     rwi->SetRenderWindow(rw);
100.     rwi->Initialize();
101.     rwi->Start();
102.
103.     return 0;
104. }

When using VTKSurfaceReconstructionFilter, mainly related to two parameters, respectively using the function SetNeighborhoodSize () and SetSampleSpacing () set.

SetNeighborhoodSize: Set the number of points in the neighborhood; which is used to estimate the points in the neighborhood of each point of the local cut plane. The default number of points in the neighborhood of 20, capable of handling most of the reconstruction. The more the number of set, the longer the time-consuming calculation. When the cloud point where Uneven distribution, consider increasing the value.

SetSampleSpacing: meshing for setting a denser grid spacing, with a small spacing, grid, generally default value 0.05.

The output of the embodiment as shown below:

2. See data

1.《C++ primer》
2.《The VTK User’s Guide – 11thEdition》

3. Zhang Xiaodong, Luo fire spirit. VTK graphic image development of advanced [M]. Machinery Industry Press, 2015.
