WebService annotation of CXF Five (profile)

1、web.xml

<?xml version="1.0" encoding="UTF-8"?>
<web-app version="3.0"
	xmlns="http://java.sun.com/xml/ns/javaee"
	xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
	xsi:schemaLocation="http://java.sun.com/xml/ns/javaee
	http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd">
  <display-name>Webservice</display-name>

  <!-- cfx webSerivice -->
    <servlet>
        <servlet-name>cxf</servlet-name>
        <servlet-class>
            org.apache.cxf.transport.servlet.CXFServlet
        </servlet-class>
        <load-on-startup>1</load-on-startup>
    </servlet>

    <servlet-mapping>
      <servlet-name>cxf</servlet-name>
      <url-pattern>/services/*</url-pattern>
    </servlet-mapping>
    <session-config>
      <session-timeout>600</session-timeout>
    </session-config>
</web-app>

2、cxf-servlet.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xmlns:jaxws="http://cxf.apache.org/jaxws"
       xmlns:soap="http://cxf.apache.org/bindings/soap"
       xsi:schemaLocation="
http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd
http://cxf.apache.org/bindings/soap http://cxf.apache.org/schemas/configuration/soap.xsd
http://cxf.apache.org/jaxws
http://cxf.apache.org/schemas/jaxws.xsd">

   <jaxws:server id="jaxwsServices" serviceClass="com.you.service.ITeacherService" address="/testTeacher">
       <jaxws:serviceBean>
                <bean class="com.you.service.impl.ITeacherServiceImpl" />
       </jaxws:serviceBean>
   </jaxws:server>
</beans>


3, run a successful outcome

May 5, 2014 11:33:44 pm org.apache.cxf.wsdl.service.factory.ReflectionServiceFactoryBean buildServiceFromClass
 Information: Creating Service {http://service.you.com/}ITeacherServiceService from class com.you.service.ITeacherService
 May 5, 2014 11:33:45 pm org.apache.cxf.services.ITeacherServiceService.ITeacherServicePort.ITeacherService
 Information: Outbound Message
---------------------------
ID: 1
Address: http://localhost:8686/Webservice/services/testTeacher
Encoding: UTF-8
Http-Method: POST
Content-Type: text/xml
Headers: {Accept=[*/*], SOAPAction=[""]}
 Payload: <soap: Envelope xmlns: soap = "http://schemas.xmlsoap.org/soap/envelope/"> <soap: Body> <ns2: findTeacherInfo xmlns: ns2 = "http://service.you.com / "> <arg0> <teacherAge> 38 </ teacherAge> <teacherName> Li Sisi </ teacherName> <teacherNum> 2007101208 </ teacherNum> <teacherQQ> 5623564545 </ teacherQQ> <teacherSex> female </ teacherSex> </ arg0> </ ns2: findTeacherInfo> </ soap: Body> </ soap: Envelope>
--------------------------------------
 May 5, 2014 11:33:45 pm org.apache.cxf.services.ITeacherServiceService.ITeacherServicePort.ITeacherService
 Information: Inbound Message
----------------------------
ID: 1
Response-Code: 200
Encoding: UTF-8
Content-Type: text/xml;charset=UTF-8
Headers: {Content-Length=[330], content-type=[text/xml;charset=UTF-8], Date=[Mon, 05 May 2014 15:33:45 GMT], Server=[Apache-Coyote/1.1]}
 Payload: <soap: Envelope xmlns: soap = "http://schemas.xmlsoap.org/soap/envelope/"> <soap: Body> <ns2: findTeacherInfoResponse xmlns: ns2 = "http://service.you.com / "> <return> teacher job number: 2007101208
 Teacher name: Li Sisi
 Teacher Age: 38
 Teacher Gender: Female
 Teacher QQ: 5623564545 </ return> </ ns2: findTeacherInfoResponse> </ soap: Body> </ soap: Envelope>
--------------------------------------
 Teacher job number: 2007101208
 Teacher name: Li Sisi
 Teacher Age: 38
 Teacher Gender: Female
 Teacher QQ: 5623564545
