1、web.xml
<?xml version="1.0" encoding="UTF-8"?>
<web-app version="3.0"
xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://java.sun.com/xml/ns/javaee
http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd">
<display-name>Webservice</display-name>
<!-- cfx webSerivice -->
<servlet>
<servlet-name>cxf</servlet-name>
<servlet-class>
org.apache.cxf.transport.servlet.CXFServlet
</servlet-class>
<load-on-startup>1</load-on-startup>
</servlet>
<servlet-mapping>
<servlet-name>cxf</servlet-name>
<url-pattern>/services/*</url-pattern>
</servlet-mapping>
<session-config>
<session-timeout>600</session-timeout>
</session-config>
</web-app>
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:jaxws="http://cxf.apache.org/jaxws"
xmlns:soap="http://cxf.apache.org/bindings/soap"
xsi:schemaLocation="
http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd
http://cxf.apache.org/bindings/soap http://cxf.apache.org/schemas/configuration/soap.xsd
http://cxf.apache.org/jaxws
http://cxf.apache.org/schemas/jaxws.xsd">
<jaxws:server id="jaxwsServices" serviceClass="com.you.service.ITeacherService" address="/testTeacher">
<jaxws:serviceBean>
<bean class="com.you.service.impl.ITeacherServiceImpl" />
</jaxws:serviceBean>
</jaxws:server>
</beans>
May 5, 2014 11:33:44 pm org.apache.cxf.wsdl.service.factory.ReflectionServiceFactoryBean buildServiceFromClass
Information: Creating Service {http://service.you.com/}ITeacherServiceService from class com.you.service.ITeacherService
May 5, 2014 11:33:45 pm org.apache.cxf.services.ITeacherServiceService.ITeacherServicePort.ITeacherService
Information: Outbound Message
---------------------------
ID: 1
Address: http://localhost:8686/Webservice/services/testTeacher
Encoding: UTF-8
Http-Method: POST
Content-Type: text/xml
Headers: {Accept=[*/*], SOAPAction=[""]}
Payload: <soap: Envelope xmlns: soap = "http://schemas.xmlsoap.org/soap/envelope/"> <soap: Body> <ns2: findTeacherInfo xmlns: ns2 = "http://service.you.com / "> <arg0> <teacherAge> 38 </ teacherAge> <teacherName> Li Sisi </ teacherName> <teacherNum> 2007101208 </ teacherNum> <teacherQQ> 5623564545 </ teacherQQ> <teacherSex> female </ teacherSex> </ arg0> </ ns2: findTeacherInfo> </ soap: Body> </ soap: Envelope>
--------------------------------------
May 5, 2014 11:33:45 pm org.apache.cxf.services.ITeacherServiceService.ITeacherServicePort.ITeacherService
Information: Inbound Message
----------------------------
ID: 1
Response-Code: 200
Encoding: UTF-8
Content-Type: text/xml;charset=UTF-8
Headers: {Content-Length=[330], content-type=[text/xml;charset=UTF-8], Date=[Mon, 05 May 2014 15:33:45 GMT], Server=[Apache-Coyote/1.1]}
Payload: <soap: Envelope xmlns: soap = "http://schemas.xmlsoap.org/soap/envelope/"> <soap: Body> <ns2: findTeacherInfoResponse xmlns: ns2 = "http://service.you.com / "> <return> teacher job number: 2007101208
Teacher name: Li Sisi
Teacher Age: 38
Teacher Gender: Female
Teacher QQ: 5623564545 </ return> </ ns2: findTeacherInfoResponse> </ soap: Body> </ soap: Envelope>
--------------------------------------
Teacher job number: 2007101208
Teacher name: Li Sisi
Teacher Age: 38
Teacher Gender: Female
Teacher QQ: 5623564545
