We have talked about color attributes in the previous section. Color attributes are a kind of attributes. In this section, we will look at how OpenGL handles attribute information from the perspective of attribute objects.

1. Point attributes

In general, we can set two attributes of a point: color and size. Let's take a look at the following example, everything is self-explanatory.

#include <GL/glut.h>
void display(void)
{
    glClear(GL_COLOR_BUFFER_BIT);
    glClearColor(1, 1, 1, 1);
    glViewport(0, 0, 400, 100);

    glViewport(0, 0, 100, 100);
    glPointSize(10.0f); glColor3f(1, 0, 0);//Point attributes
    glBegin(GL_POINTS);
    glVertex2f(0.0f, 0.0f);
    glEnd();

    glViewport(100, 0, 100, 100);
    glPointSize(20.0f); glColor3f(0, 1, 0);
    glBegin(GL_POINTS);
    glVertex2f(0.0f, 0.0f);
    glEnd();

    glViewport(200, 0, 100, 100);
    glPointSize(30.0f); glColor3f(0, 0, 1);
    glBegin(GL_POINTS);
    glVertex2f(0.0f, 0.0f);
    glEnd();

    glViewport(300, 0, 100, 100);
    glPointSize(40.0f); glColor3f(1, 1, 0);
    glBegin(GL_POINTS);
    glVertex2f(0.0f, 0.0f);
    glEnd();

    glFlush();
}
int main(int argc, char ** argv)
{
    glutInit(&argc, argv);
    glutInitDisplayMode(GLUT_RGB | GLUT_SINGLE);
    glutInitWindowSize(400, 100);
    glutInitWindowPosition(100, 100);
    glutCreateWindow("Hello OpenGL");
    glutDisplayFunc(display);
    glutMainLoop();
    return 0;
}

Although the code is long, we only care about two lines of code.

glPointSize(10.0f); //Point size
glColor3f(1, 0, 0);//Point color

These two lines of code respectively represent the two attributes of the point: size and color. We have explained the color attributes very thoroughly before, let's focus on the size or size attributes. The size of a point in OpenGL is an integral multiple of the pixel size, so as shown in the example, a large point is displayed as a pixel square. OpenGL uses the glPointSize(size) function to set the size of a point, where size is specified with a positive floating point number, and the number of horizontal and vertical pixels that display the point is the size of size.

Second, the attributes of the line

Line segments can be displayed using three basic attributes: color, line width and line style.

#include <GL/glut.h>
#include <math.h>
double Pi = 3.1415926;
void display(void)
{
    GLfloat r = 1.2f;
    GLfloat verA[2] = { 0, r };
    GLfloat verB[2] = { -r*sin(0.4*Pi), r*cos(0.4*Pi) };
    GLfloat verC[2] = { -r*sin(Pi / 5), -r*cos(Pi / 5) };
    GLfloat verD[2] = { r*sin(Pi / 5), -r*cos(Pi / 5) };
    GLfloat verE[2] = { r*sin(0.4*Pi), r*cos(0.4*Pi) };
    glEnable(GL_LINE_STIPPLE);//Enable line type
    glLineStipple(1, 0x0101);//Set the line type to dashed line
    glLineWidth(6.0f);//Line width
    glClear(GL_COLOR_BUFFER_BIT);
    glBegin(GL_LINE_LOOP);
    glVertex2fv(verA);
    glColor3f(1.0f, 0, 0);
    glVertex2fv(verC);
    glColor3f(0, 1.0f, 0);
    glVertex2fv(verE);
    glColor3f(0, 0, 1.0f);
    glVertex2fv(verB);
    glColor3f(1.0, 1.0, 1.0);
    glVertex2fv(verD);
    glEnd();
    glFinish();
}
int main(int argc, char ** argv)
{
    glutInit(&argc, argv);
    glutInitDisplayMode(GLUT_RGB | GLUT_SINGLE);
    glutInitWindowSize(400, 400);
    glutInitWindowPosition(500, 300);
    glutCreateWindow("Hello OpenGL");
    glutDisplayFunc(display);
    glutMainLoop();
    return 0;
}

I believe you can find the core code at a glance. , Let's analyze them one by one.
We won't go into details about the color attributes. The line width attributes are similar to the point size attributes, and they are relatively simple. The most interesting thing for us is undoubtedly the linear attribute.
Before using the current line type to display line segments, you must first activate the OpenGL line type feature:

glEnable(GL_LINE_STIPPLE);

OpenGL uses the glLineStipple function to set the line style. It has two parameters. The second parameter introduces a 16-bit integer describing how to display the line segment. A bit with a value of 1 corresponds to an "on" pixel, and a bit with a value of 0 corresponds to an "off". "Pixels. This mode is applied to the line path from the low bit. In our example, the parameter is 0x0101, and the corresponding binary number is 0000000100000001, which is a triple-width dot mode. The dotted line is represented by dots, and the interval between dots is wide. It should be noted that because we set the line width to 6, the dashed lines seem to be connected by dashed lines, but here it is obvious that the dashed line direction is perpendicular to the direction of the dashed line, which indicates that the width represents the width of the dashed line, not The interval is wide. The first parameter represents the number of repeated applications for each bit. Let's try to change this parameter to 4 and see the result.

The result is also obvious. The dots and intervals are widened in the direction of the dotted line. This is the result of repeating each bit 4 times.
Let’s show you a few more examples for your understanding.
The second parameter is changed to 0x1c47:

The second parameter is changed to 0x00ff:

Have we finished this code? Obviously, everyone still has doubts.
Why are the colors in the picture so colorful? We obviously only set the color four times. Let's learn a new function:

glShadeModel(GL_SMOOTH);

This function specifies that the line segment is displayed in a linear interpolation mode of the colors of the two ends, that is, to achieve such an effect of color gradient. In fact, we did not use this function in the code, because the color gradient is a default effect in OpenGL. We can change the function parameter to GL_FLAT to cancel the color gradient effect, and instead always use the color at the end of the line segment to represent the entire line segment.
