reference

The brightness and contrast adjustment formula, where alpha is responsible for contrast and beta is responsible for brightness.

O(x,y) = alpha * I(x,y) + beta

If you want to adjust the brightness and contrast automatically, it means automatic adjustmentalpha with beta
If you want to change the minimum value to 0 and the maximum value to 255, the formula is as follows.

input range = max(I) - min(I)
wanted output range = 255;
alpha = output range / input range = 255 / ( max(I) - min(I) )
min(O) = alpha * min(I) + beta
beta = -min(I) * alpha

Histogram pruning

• Pan -> Brightness
• Pruning -> Redefine the extent of the histogram

The following figure is for understanding

Code

Here I added two parameters to adjust the minimum brightness and histogram range.

// clipHistPercent pruning (how many percentages of total pixels are cut)
// histSize finally sets the range of all gray values ​​to
// lowhist minimum gray value
void BrightnessAndContrastAuto(const cv::Mat &src, cv::Mat &dst, float clipHistPercent=0, int histSize = 255, int lowhist = 0)
{

    CV_Assert(clipHistPercent >= 0);
    CV_Assert((src.type() == CV_8UC1) || (src.type() == CV_8UC3) || (src.type() == CV_8UC4));

    float alpha, beta;
    double minGray = 0, maxGray = 0;

    //to calculate grayscale histogram
    cv::Mat gray;
    if (src.type() == CV_8UC1) gray = src;
    else if (src.type() == CV_8UC3) cvtColor(src, gray, CV_BGR2GRAY);
    else if (src.type() == CV_8UC4) cvtColor(src, gray, CV_BGRA2GRAY);
    if (clipHistPercent == 0)
    {
        // keep full available range
        cv::minMaxLoc(gray, &minGray, &maxGray);
    }
    else
    {
        cv::Mat hist; //the grayscale histogram

        float range[] = { 0, 256 };
        const float* histRange = { range };
        bool uniform = true;
        bool accumulate = false;
        calcHist(&gray, 1, 0, cv::Mat (), hist, 1, &histSize, &histRange, uniform, accumulate);

        // calculate cumulative distribution from the histogram
        std::vector<float> accumulator(histSize);
        accumulator[0] = hist.at<float>(0);
        for (int i = 1; i < histSize; i++)
        {
            accumulator[i] = accumulator[i - 1] + hist.at<float>(i);
        }

        // locate points that cuts at required value
        float max = accumulator.back();

        int clipHistPercent2;
        clipHistPercent2 = clipHistPercent * (max / 100.0); //make percent as absolute
        clipHistPercent2 /= 2.0; // left and right wings
        // locate left cut
        minGray = 0;
        while (accumulator[minGray] < clipHistPercent2)
            minGray++;

        // locate right cut
        maxGray = histSize - 1;
        while (accumulator[maxGray] >= (max - clipHistPercent2))
            maxGray--;
    }

    // current range
    float inputRange = maxGray - minGray;

    alpha = (histSize - 1) / inputRange;   // alpha expands current range to histsize range
    beta = -minGray * alpha + lowhist;             // beta shifts current range so that minGray will go to 0

    // Apply brightness and contrast normalization
    // convertTo operates with saurate_cast
    src.convertTo(dst, -1, alpha, beta);

    // restore alpha channel from source
    if (dst.type() == CV_8UC4)
    {
        int from_to[] = { 3, 3};
        cv::mixChannels(&src, 4, &dst,1, from_to, 1);
    }
}
