1. Introduction to USB interface

By monitoring the USB interface traffic, you can obtain keyboard keystrokes, mouse movements and clicks, clear text transmission communication of storage devices, and network transmission content of USB wireless network cards.

2. Title

After wireshark opened the data packet, it was found to be the usb protocol

The USB protocol data part is in the Leftover Capture Data field, use the tshark command to extract it separately

tshark -r udn.pcapng -T fields -e usb.capdata > usbdata.txt

cat command to view the separated usbdata.txt

cat usbdata.txt

Since USB traffic is divided into keyboard traffic and mouse traffic, the data length of keyboard data packets is eight bytes, and the data length of mouse data packets is four bytes.
The keystroke information of the keyboard data packet is concentrated in the third byte. Each key stroke will generate a keyboard event usb packet.
The first byte of the mouse data packet represents the button. When 0×00 is taken, it means no key is pressed; when 0×01 is taken, it means pressing the left button; when 0×02 is taken, it means the current The button is the right button. The second byte can be regarded as a signed byte type, and its highest bit is the sign bit. When the value is positive, it means the mouse moves the pixel to the right; when the value is negative, the mouse moves the pixel to the left. The third byte represents the offset of the vertical up and down movement.
This title is keyboard data package

Friendly link USB protocol, find the corresponding relationship between the value and the specific key position:
http://www.usb.org/developers/hidpage/Hut1_12v2.pdf

Write the script and decode the data packet according to the usb keyboard mapping table on page 53

Upload script

mappings = { 0x04:"A",  0x05:"B",  0x06:"C", 0x07:"D", 0x08:"E", 0x09:"F", 0x0A:"G",  0x0B:"H", 0x0C:"I",  0x0D:"J", 0x0E:"K", 0x0F:"L", 0x10:"M", 0x11:"N",0x12:"O",  0x13:"P", 0x14:"Q", 0x15:"R", 0x16:"S", 0x17:"T", 0x18:"U",0x19:"V", 0x1A:"W", 0x1B:"X", 0x1C:"Y", 0x1D:"Z", 0x1E:"1", 0x1F:"2", 0x20:"3", 0x21:"4", 0x22:"5",  0x23:"6", 0x24:"7", 0x25:"8", 0x26:"9", 0x27:"0", 0x28:"\n", 0x2a:"[DEL]",  0X2B:"    ", 0x2C:" ",  0x2D:"-", 0x2E:"=", 0x2F:"[",  0x30:"]",  0x31:"\\", 0x32:"~", 0x33:";",  0x34:"'", 0x36:",",  0x37:"." }
nums = []
keys = open('usbdata.txt')
for line in keys:
    if line[0]!='0' or line[1]!='0' or line[3]!='0' or line[4]!='0' or line[9]!='0' or line[10]!='0' or line[12]!='0' or line[13]!='0' or line[15]!='0' or line[16]!='0' or line[18]!='0' or line[19]!='0' or line[21]!='0' or line[22]!='0':
         continue
    nums.append(int(line[6:8],16))
keys.close()
output = ""
for n in nums:
    if n == 0 :
        continue
    if n in mappings:
        output += mappings[n]
print 'output :\n' + output

attached mouse script

nums = []
keys = open('data.txt','r')
posx = 0
posy = 0
for line in keys:
if len(line) != 12 :
     continue
x = int(line[3:5],16)
y = int(line[6:8],16)
if x > 127 :
    x -= 256
if y > 127 :
    y -= 256
posx += x
posy += y
btn_flag = int(line[0:2],16)  # 1 for left , 2 for right , 0 for nothing
if btn_flag == 1 :
    print posx , posy
keys.close()
