There are 3 types of ALV color settings: row, column, and cell.
 1. Column color settings
 In slis_t_fieldcat_alv-emphasize, write the required color code.
Eg:
DATA: fc TYPE slis_t_fieldcat_alv WITH HEADER LINE.
        fc-tabname = 'ITAB'.
         fc-fieldname = 'COL'.
         fc-emphasize = 'C100'.
         append fc.

 2. Setting of row color
 a. In the itab to be output, add the color column, the type is C (4), and record the required color code.
 b. Set the layout. alv_layout-info_fieldname ='COLOR'.
Eg: DATA: BEGIN OF itab OCCURS 0.
   INCLUDE STRUCTURE mara.
    DATA: color(4) TYPE c.
    DATA: END OF itab.

    DATA: alv_layout TYPE slis_layout_alv.

    itab-matnr = '123'.
    itab-color = 'C200'.
    APPEND itab.

    alv_layout-info_fieldname = 'COLOR'.

 3. Cell color settings
 a. In the itab to be output, add the color column, the type is slis_t_specialcol_alv, and record the required color code.
 b. Set the layout. alv_layout-coltab_fieldname ='COLOR'.

Eg: DATA: BEGIN OF itab OCCURS 0.
   INCLUDE STRUCTURE mara.
    DATA: color TYPE slis_t_specialcol_alv.
    DATA: END OF itab.

    DATA: color TYPE slis_t_specialcol_alv.
    DATA: alv_layout TYPE slis_layout_alv.

    color-color-col = '1'.
    color-color-int = '0'.
    color-color-inv = '0'.
    color-fieldname = 'COL'.
    APPEND color.

    itab-matnr = '123'.
    itab-color[] = color[].
    APPEND itab.

    alv_layout-coltab_fieldname = 'COLOR'.

 The above is a summary of my ALV GRID coloring method. Due to the limited technical level, there may be some omissions, and I hope you can point out.

 Example code:

REPORT ztest.

 "Double-click the cell to enter the new ALV screen.

TYPE-POOLS: slis.

 *A total of 3 internal tables are defined.
 *itab1: set the column color,
 *itab2: Set the row color.
 *itab3: Set the cell color.

DATA: BEGIN OF itab_test OCCURS 0,
        col1(4) TYPE c,
        col2(4) TYPE c,
        col3(4) TYPE c,
        col4(4) TYPE c,
        col5(4) TYPE c,
        col6(4) TYPE c,
      END OF itab_test .

DATA: BEGIN OF itab_test2 OCCURS 0.
        INCLUDE STRUCTURE itab_test.
DATA: color(4) TYPE c.
DATA: END OF itab_test2.

DATA: BEGIN OF itab_test3 OCCURS 0.
        INCLUDE STRUCTURE itab_test.
DATA: color TYPE slis_t_specialcol_alv.
DATA: END OF itab_test3.

DATA: fc TYPE slis_t_fieldcat_alv WITH HEADER LINE,
      fc2 TYPE slis_t_fieldcat_alv WITH HEADER LINE,
      fc3 TYPE slis_t_fieldcat_alv WITH HEADER LINE.

START-OF-SELECTION.
PERFORM create_data.

END-OF-SELECTION.
PERFORM fieldcat_build.
PERFORM show_alv.

*&---------------------------------------------------------------------*
*&      Form create_data
*&---------------------------------------------------------------------*
*       text
*----------------------------------------------------------------------*
FORM create_data.

DATA: l_color(4) TYPE c,
        l_char TYPE c,
        i TYPE i.
DATA: color TYPE slis_t_specialcol_alv WITH HEADER LINE.

REFRESH itab_test.
REFRESH itab_test2.
REFRESH itab_test3.
REFRESH fc.
REFRESH fc2.
REFRESH fc3.

WHILE sy-index < 8.
 * Internal table 1
    itab_test-col1 = ( sy-index - 1 ) * 6 + 1.
    itab_test-col2 = ( sy-index - 1 ) * 6 + 2.
    itab_test-col3 = ( sy-index - 1 ) * 6 + 3.
    itab_test-col4 = ( sy-index - 1 ) * 6 + 4.
    itab_test-col5 = ( sy-index - 1 ) * 6 + 5.
    itab_test-col6 = ( sy-index - 1 ) * 6 + 6.
    APPEND itab_test.

 * Internal table 2
    MOVE-CORRESPONDING itab_test TO itab_test2.
    l_char = sy-index.

    i = sy-index MOD 2.
    IF i = 0.
      CONCATENATE 'C' l_char '01' INTO l_color.
    ELSE.
      CONCATENATE 'C' l_char '10' INTO l_color.
    ENDIF.
    itab_test2-color = l_color.
    APPEND itab_test2.

 * Internal table 3
    MOVE-CORRESPONDING itab_test TO itab_test3.
    REFRESH color.

    color-color-col = l_char.

    color-color-int = '0'.
    color-color-inv = '0'.
    color-fieldname = 'COL1'. APPEND color.
    CONCATENATE l_char '00' INTO itab_test3-col1.

    color-color-int = '0'.
    color-color-inv = '1'.
    color-fieldname = 'COL2'. APPEND color.
    CONCATENATE l_char '01' INTO itab_test3-col2.

    color-color-int = '1'.
    color-color-inv = '0'.
    color-fieldname = 'COL3'. APPEND color.
    CONCATENATE l_char '10' INTO itab_test3-col3.

    itab_test3-color[] = color[].
    APPEND itab_test3.

ENDWHILE.

ENDFORM.                    "create_data

************************************************************************
FORM fieldcat_build.
DATA: BEGIN OF fc_struct,
          tabname(10),
          fieldname(5),
          seltext_m(5),
          emphasize(4),
        END OF fc_struct.
DEFINE ac.
    clear: fc,fc2,fc_struct.
    fc_struct = &1.
         fc-tabname = fc_struct-tabname. "Internal table name
         fc-fieldname = fc_struct-fieldname. "Field name
         fc-seltext_m = fc_struct-seltext_m. "Field description
         fc-emphasize = fc_struct-emphasize. "Column color
    append fc.

         fc2-tabname = fc_struct-tabname. "Internal table name
         fc2-fieldname = fc_struct-fieldname. "Field name
         fc2-seltext_m = fc_struct-seltext_m. "Field description
    append fc2.

    if fc3-fieldname < 'COL4'.
             fc3-tabname = fc_struct-tabname. "Internal table name
             fc3-fieldname = fc_struct-fieldname. "Field name
             fc3-seltext_m = fc_struct-seltext_m. "Field description
      append fc3.
    endif.
END-OF-DEFINITION.

ac 'ITAB_TEST COL1 COL1 C100'.
ac 'ITAB_TEST COL2 COL2 C200'.
ac 'ITAB_TEST COL3 COL3 C300'.
ac 'ITAB_TEST COL4 COL4 C400'.
ac 'ITAB_TEST COL5 COL5 C500'.
ac 'ITAB_TEST COL6 COL6 C600'.

ENDFORM.                    "fieldcat_build

*&---------------------------------------------------------------------*
*&      Form show_alv
*&---------------------------------------------------------------------*
 * Show inner table 1
*----------------------------------------------------------------------*
FORM show_alv.

CALL FUNCTION 'REUSE_ALV_GRID_DISPLAY'
    EXPORTING
      i_callback_program      = sy-repid
      it_fieldcat             = fc[]
      i_callback_user_command = 'PROCESS_USER_COMMAND_1'
      i_save                  = 'A'
    TABLES
      t_outtab                = itab_test
    EXCEPTIONS
      program_error           = 1
      OTHERS                  = 2.

IF sy-subrc <> 0.
    MESSAGE ID sy-msgid TYPE sy-msgty NUMBER sy-msgno
            WITH sy-msgv1 sy-msgv2 sy-msgv3 sy-msgv4.
ENDIF.
ENDFORM.                    "show_alv

*&---------------------------------------------------------------------*
*&      Form PROCESS_USER_COMMAND_1
*&---------------------------------------------------------------------*
*       text
*----------------------------------------------------------------------*
*      -->UCOMM        text
*      -->RS_SELFIELD text
*----------------------------------------------------------------------*
FORM process_user_command_1 USING ucomm
               rs_selfield TYPE slis_selfield.

IF rs_selfield-fieldname <> space AND rs_selfield-tabindex > 0.
    PERFORM show_alv_2.
ENDIF.

ENDFORM.                    "PROCESS_USER_COMMAND_1

*&---------------------------------------------------------------------*
*&      Form show_alv_2
*&---------------------------------------------------------------------*
 * Show inner table 2
*----------------------------------------------------------------------*
FORM show_alv_2.
DATA: alv_layout       TYPE slis_layout_alv.

alv_layout-info_fieldname = 'COLOR'.

CALL FUNCTION 'REUSE_ALV_GRID_DISPLAY'
    EXPORTING
      i_callback_program      = sy-repid
      it_fieldcat             = fc2[]
      i_callback_user_command = 'PROCESS_USER_COMMAND_2'
      is_layout               = alv_layout
      i_save                  = 'U'
    TABLES
      t_outtab                = itab_test2
    EXCEPTIONS
      program_error           = 1
      OTHERS                  = 2.

IF sy-subrc <> 0.
    MESSAGE ID sy-msgid TYPE sy-msgty NUMBER sy-msgno
            WITH sy-msgv1 sy-msgv2 sy-msgv3 sy-msgv4.
ENDIF.
ENDFORM.                                                    "show_alv_2

*&---------------------------------------------------------------------*
*&      Form PROCESS_USER_COMMAND_2
*&---------------------------------------------------------------------*
*       text
*----------------------------------------------------------------------*
*      -->UCOMM        text
*      -->RS_SELFIELD text
*----------------------------------------------------------------------*
FORM process_user_command_2 USING ucomm
               rs_selfield TYPE slis_selfield.

IF rs_selfield-fieldname <> space AND rs_selfield-tabindex > 0.
    PERFORM show_alv_3.
ENDIF.

ENDFORM.                    "PROCESS_USER_COMMAND_2

*&---------------------------------------------------------------------*
*&      Form show_alv_3
*&---------------------------------------------------------------------*
 * Show inner table 3
*----------------------------------------------------------------------*
FORM show_alv_3.
DATA: alv_layout       TYPE slis_layout_alv.

alv_layout-coltab_fieldname = 'COLOR'.

CALL FUNCTION 'REUSE_ALV_GRID_DISPLAY'
    EXPORTING
      i_callback_program = sy-repid
      it_fieldcat        = fc3[]
      is_layout          = alv_layout
      i_save             = 'U'
    TABLES
      t_outtab           = itab_test3
    EXCEPTIONS
      program_error      = 1
      OTHERS             = 2.

IF sy-subrc <> 0.
    MESSAGE ID sy-msgid TYPE sy-msgty NUMBER sy-msgno
            WITH sy-msgv1 sy-msgv2 sy-msgv3 sy-msgv4.
ENDIF.
ENDFORM.                                                    "show_alv_3
