Orchestrator Interpretation

first part

Recently developed Orchestrator twice, so I studied the code of the elegant switch section.

Entrance

First, use the Orchestrator-Client as a client request entry to describe:
The code is located:

orchestrator/resources/bin/orchestrator-client

main：

function main {
  check_requirements
  detect_leader_api

  instance_hostport=$(to_hostport $instance)
  destination_hostport=$(to_hostport $destination)

  run_command
}
 The code is mainly located in this section of Run_Command.
 Find an elegant switch module: graceful-master-takeover-auto

function graceful_master_takeover_auto {
  assert_nonempty "instance|alias" "${alias:-$instance}"
  if [ -z "$destination_hostport" ] ; then
    # No destination given.
    api "graceful-master-takeover-auto/${alias:-$instance}"
  else
    # Explicit destination (designated master) given
         # Here I request the API of the Server end.
    api "graceful-master-takeover-auto/${alias:-$instance}/${destination_hostport}"
  fi
  print_details | jq '.SuccessorKey' | print_key
}

The API code path of the Server end is:

go/http/api.go

 API entry function:
func (this *HttpAPI) registerAPIRequestInternal(m *martini.ClassicMartini, path string, handler martini.Handler, allowProxy bool)
...
	this.registerAPIRequest(m, "graceful-master-takeover/:host/:port", this.GracefulMasterTakeover)
	this.registerAPIRequest(m, "graceful-master-takeover/:host/:port/:designatedHost/:designatedPort", this.GracefulMasterTakeover)
	this.registerAPIRequest(m, "graceful-master-takeover/:clusterHint", this.GracefulMasterTakeover)
	this.registerAPIRequest(m, "graceful-master-takeover/:clusterHint/:designatedHost/:designatedPort", this.GracefulMasterTakeover)
	this.registerAPIRequest(m, "graceful-master-takeover-auto/:host/:port", this.GracefulMasterTakeoverAuto)
	this.registerAPIRequest(m, "graceful-master-takeover-auto/:host/:port/:designatedHost/:designatedPort", this.GracefulMasterTakeoverAuto)
	this.registerAPIRequest(m, "graceful-master-takeover-auto/:clusterHint", this.GracefulMasterTakeoverAuto)
	this.registerAPIRequest(m, "graceful-master-takeover-auto/:clusterHint/:designatedHost/:designatedPort", this.GracefulMasterTakeoverAuto)

func (this *HttpAPI) GracefulMasterTakeoverAuto(params martini.Params, r render.Render, req *http.Request, user auth.User) {
	this.gracefulMasterTakeover(params, r, req, user, true)
}

Then we find the code module of the API elegant switch:

func (this *HttpAPI) gracefulMasterTakeover(params martini.Params, r render.Render, req *http.Request, user auth.User, auto bool) {
	if !isAuthorizedForAction(req, user) {
		Respond(r, &APIResponse{Code: ERROR, Message: "Unauthorized"})
		return
	}
	// Get the cluster name of the entire cluster, the default is the HostName: Port Name of the instance
	clusterName, err := figureClusterName(getClusterHint(params))
	if err != nil {
		Respond(r, &APIResponse{Code: ERROR, Message: err.Error()})
		return
	}
	 // Incoming in, is specific instance, here acquisition
	designatedKey, _ := this.getInstanceKey(params["designatedHost"], params["designatedPort"])
	// designatedKey may be empty/invalid
	 // This calls the GracefulmastertakeOver under the Logic package, the real switching logic -> Elegant switching module
	 // Files in: go / logic / topology_recovery.go
	topologyRecovery, _, err := logic.GracefulMasterTakeover(clusterName, &designatedKey, auto)
	if err != nil {
		Respond(r, &APIResponse{Code: ERROR, Message: err.Error(), Details: topologyRecovery})
		return
	}
	if topologyRecovery == nil || topologyRecovery.SuccessorKey == nil {
		Respond(r, &APIResponse{Code: ERROR, Message: "graceful-master-takeover: no successor promoted", Details: topologyRecovery})
		return
	}
	Respond(r, &APIResponse{Code: OK, Message: "graceful-master-takeover: successor promoted", Details: topologyRecovery})
}

topology_recovery.go:

/ / Here is an elegant switching backend code entry for logic switches.
func GracefulMasterTakeover(clusterName string, designatedKey *inst.InstanceKey, auto bool) (topologyRecovery *TopologyRecovery, promotedMasterCoordinates *inst.BinlogCoordinates, err error) {
// inst.readclustermaster -> According to the incoming cluster name, read the main library of the cluster. Here is the database to go to the backend, and execute a SQL statement:
###############################################################
select
			*,
			unix_timestamp() - unix_timestamp(last_checked) as seconds_since_last_checked,
			ifnull(last_checked <= last_seen, 0) as is_last_check_valid,
			unix_timestamp() - unix_timestamp(last_seen) as seconds_since_last_seen,
			candidate_database_instance.last_suggested is not null
				 and candidate_database_instance.promotion_rule in ('must', 'prefer') as is_candidate,
			ifnull(nullif(candidate_database_instance.promotion_rule, ''), 'neutral') as promotion_rule,
			ifnull(unresolved_hostname, '') as unresolved_hostname,
			(database_instance_downtime.downtime_active is not null and ifnull(database_instance_downtime.end_timestamp, now()) > now()) as is_downtimed,
    	ifnull(database_instance_downtime.reason, '') as downtime_reason,
			ifnull(database_instance_downtime.owner, '') as downtime_owner,
			ifnull(unix_timestamp() - unix_timestamp(begin_timestamp), 0) as elapsed_downtime_seconds,
    	ifnull(database_instance_downtime.end_timestamp, '') as downtime_end_timestamp
		from
			database_instance
			left join candidate_database_instance using (hostname, port)
			left join hostname_unresolve using (hostname)
			left join database_instance_downtime using (hostname, port)
		where
		cluster_name = 'xxxxx'
		and (replication_depth = 0 or is_co_master)
###############################################################
	clusterMasters, err := inst.ReadClusterMaster(clusterName)
	if err != nil {
		return nil, nil, fmt.Errorf("Cannot deduce cluster master for %+v; error: %+v", clusterName, err)
	}
	// If the cluster doesn't have a master or there are several, then directly return failed
	if len(clusterMasters) != 1 {
		return nil, nil, fmt.Errorf("Cannot deduce cluster master for %+v. Found %+v potential masters", clusterName, len(clusterMasters))
	}
	// Returns an array, so take the first value, this is the Master Instance Name
	clusterMaster := clusterMasters[0]

	clusterMasterDirectReplicas, err := inst.ReadReplicaInstances(&clusterMaster.Key)
	if err != nil {
		return nil, nil, log.Errore(err)
	}

	if len(clusterMasterDirectReplicas) == 0 {
		return nil, nil, fmt.Errorf("Master %+v doesn't seem to have replicas", clusterMaster.Key)
	}

	if designatedKey != nil && !designatedKey.IsValid() {
		// An empty or invalid key is as good as no key
		designatedKey = nil
	}
	designatedInstance, err := getGracefulMasterTakeoverDesignatedInstance(&clusterMaster.Key, designatedKey, clusterMasterDirectReplicas, auto)
	if err != nil {
		return nil, nil, log.Errore(err)
	}

	if inst.IsBannedFromBeingCandidateReplica(designatedInstance) {
		return nil, nil, fmt.Errorf("GracefulMasterTakeover: designated instance %+v cannot be promoted due to promotion rule or it is explicitly ignored in PromotionIgnoreHostnameFilters configuration", designatedInstance.Key)
	}

	masterOfDesignatedInstance, err := inst.GetInstanceMaster(designatedInstance)
	if err != nil {
		return nil, nil, err
	}
	if !masterOfDesignatedInstance.Key.Equals(&clusterMaster.Key) {
		return nil, nil, fmt.Errorf("Sanity check failure. It seems like the designated instance %+v does not replicate from the master %+v (designated instance's master key is %+v). This error is strange. Panicking", designatedInstance.Key, clusterMaster.Key, designatedInstance.MasterKey)
	}
	if !designatedInstance.HasReasonableMaintenanceReplicationLag() {
		return nil, nil, fmt.Errorf("Desginated instance %+v seems to be lagging to much for thie operation. Aborting.", designatedInstance.Key)
	}

	if len(clusterMasterDirectReplicas) > 1 {
		log.Infof("GracefulMasterTakeover: Will let %+v take over its siblings", designatedInstance.Key)
		relocatedReplicas, _, err, _ := inst.RelocateReplicas(&clusterMaster.Key, &designatedInstance.Key, "")
		if len(relocatedReplicas) != len(clusterMasterDirectReplicas)-1 {
			// We are unable to make designated instance master of all its siblings
			relocatedReplicasKeyMap := inst.NewInstanceKeyMap()
			relocatedReplicasKeyMap.AddInstances(relocatedReplicas)
			// Let's see which replicas have not been relocated
			for _, directReplica := range clusterMasterDirectReplicas {
				if relocatedReplicasKeyMap.HasKey(directReplica.Key) {
					// relocated, good
					continue
				}
				if directReplica.Key.Equals(&designatedInstance.Key) {
					// obviously we skip this one
					continue
				}
				if directReplica.IsDowntimed {
					// obviously we skip this one
					log.Warningf("GracefulMasterTakeover: unable to relocate %+v below designated %+v, but since it is downtimed (downtime reason: %s) I will proceed", directReplica.Key, designatedInstance.Key, directReplica.DowntimeReason)
					continue
				}
				return nil, nil, fmt.Errorf("Desginated instance %+v cannot take over all of its siblings. Error: %+v", designatedInstance.Key, err)
			}
		}
	}
	log.Infof("GracefulMasterTakeover: Will demote %+v and promote %+v instead", clusterMaster.Key, designatedInstance.Key)

	replicationCreds, replicationCredentialsError := inst.ReadReplicationCredentials(&designatedInstance.Key)

	analysisEntry, err := forceAnalysisEntry(clusterName, inst.DeadMaster, inst.GracefulMasterTakeoverCommandHint, &clusterMaster.Key)
	if err != nil {
		return nil, nil, err
	}
	preGracefulTakeoverTopologyRecovery := &TopologyRecovery{
		SuccessorKey:  &designatedInstance.Key,
		AnalysisEntry: analysisEntry,
	}
	if err := executeProcesses(config.Config.PreGracefulTakeoverProcesses, "PreGracefulTakeoverProcesses", preGracefulTakeoverTopologyRecovery, true); err != nil {
		return nil, nil, fmt.Errorf("Failed running PreGracefulTakeoverProcesses: %+v", err)
	}

	log.Infof("GracefulMasterTakeover: Will set %+v as read_only", clusterMaster.Key)
	if clusterMaster, err = inst.SetReadOnly(&clusterMaster.Key, true); err != nil {
		return nil, nil, err
	}
	demotedMasterSelfBinlogCoordinates := &clusterMaster.SelfBinlogCoordinates
	log.Infof("GracefulMasterTakeover: Will wait for %+v to reach master coordinates %+v", designatedInstance.Key, *demotedMasterSelfBinlogCoordinates)
	if designatedInstance, _, err = inst.WaitForExecBinlogCoordinatesToReach(&designatedInstance.Key, demotedMasterSelfBinlogCoordinates, time.Duration(config.Config.ReasonableMaintenanceReplicationLagSeconds)*time.Second); err != nil {
		return nil, nil, err
	}
	promotedMasterCoordinates = &designatedInstance.SelfBinlogCoordinates

	log.Infof("GracefulMasterTakeover: attempting recovery")
	recoveryAttempted, topologyRecovery, err := ForceExecuteRecovery(analysisEntry, &designatedInstance.Key, false)
	if err != nil {
		log.Errorf("GracefulMasterTakeover: noting an error, and for now proceeding: %+v", err)
	}
	if !recoveryAttempted {
		return nil, nil, fmt.Errorf("GracefulMasterTakeover: unexpected error: recovery not attempted. This should not happen")
	}
	if topologyRecovery == nil {
		return nil, nil, fmt.Errorf("GracefulMasterTakeover: recovery attempted but with no results. This should not happen")
	}
	if topologyRecovery.SuccessorKey == nil {
		// Promotion fails.
		// Undo setting read-only on original master.
		inst.SetReadOnly(&clusterMaster.Key, false)
		return nil, nil, fmt.Errorf("GracefulMasterTakeover: Recovery attempted yet no replica promoted; err=%+v", err)
	}
	var gtidHint inst.OperationGTIDHint = inst.GTIDHintNeutral
	if topologyRecovery.RecoveryType == MasterRecoveryGTID {
		gtidHint = inst.GTIDHintForce
	}
	clusterMaster, err = inst.ChangeMasterTo(&clusterMaster.Key, &designatedInstance.Key, promotedMasterCoordinates, false, gtidHint)
	if !clusterMaster.SelfBinlogCoordinates.Equals(demotedMasterSelfBinlogCoordinates) {
		log.Errorf("GracefulMasterTakeover: sanity problem. Demoted master's coordinates changed from %+v to %+v while supposed to have been frozen", *demotedMasterSelfBinlogCoordinates, clusterMaster.SelfBinlogCoordinates)
	}
	if !clusterMaster.HasReplicationCredentials && replicationCredentialsError == nil {
		_, credentialsErr := inst.ChangeMasterCredentials(&clusterMaster.Key, replicationCreds)
		if err == nil {
			err = credentialsErr
		}
	}
	if designatedInstance.AllowTLS {
		_, enableSSLErr := inst.EnableMasterSSL(&clusterMaster.Key)
		if err == nil {
			err = enableSSLErr
		}
	}
	if auto {
		_, startReplicationErr := inst.StartReplication(&clusterMaster.Key)
		if err == nil {
			err = startReplicationErr
		}
	}
	executeProcesses(config.Config.PostGracefulTakeoverProcesses, "PostGracefulTakeoverProcesses", topologyRecovery, false)

	return topologyRecovery, promotedMasterCoordinates, err
}
