GC

Action area:

When the JVM performs GC, it does not uniformly recycle these three areas. Most of the time, recycling is the new generation

• Cenozoic

• Survival area (form, to)

• elderly area

  Two types of GC: light GC (ordinary GC) (new generation, survivor area), heavy GC (global GC) (all)

  GC topic:

  1. The memory model and partition of the JVM, what is placed in each area in detail?

  Depend onstack, heap, native method stack, method area, program counter

  • Stack: method, object reference, 8 basic data types

  • Heap: object of instance, member variable (non-static)

  • Method area: The method area is shared by all threads, and the information of all defined methods is stored in this area, statically modified variables and methods, final modified, class information, constant pool

  • Program Counter: Stores the address that points to the next instruction

  • Native method stack: It registers native methods and loads Native Libraies (native libraries) when (Execution Engine) executes the engine.

  2. What are the partitions in the heap? talk about their characteristics

  Eden, from, to, old age,

  • Eden: All objects come out of this new, which is where objects are born, grow, and possibly die. After each GC, Eden becomes empty again, because most of the objects we create are temporary objects, so the elimination rate of objects is still very high, which is suitable for the GC replication algorithm (copy the objects from from to to, and then two exchange identities).

  • from and to: After being cleared by GC, the surviving object will be moved to to, it is dynamically exchanged with from, and to is always empty

  • Old age: Objects in the survivor area will be moved to the old age after a certain number of clears. Objects in this area will be difficult to kill, and the cost of using the copy algorithm is too high. It is suitable for GC's mark clearing algorithm and mark Combination of compression algorithms

  3. What are the GC algorithms?

  • replication algorithm
  • mark clear
  • tag compression

  4. When do light GC and heavy GC happen?

  When the Eden object is full, a light GC will be triggered, and when the objects stored in the old age are full, a heavy GC will be triggered

reference counting

Each object has a counter, space consumption

Because it's not efficient, the jvm doesn't use it

replication algorithm

The question of who is to, who is free and who is to

1. Each GC will move the living objects of the Eden area to the survivor area.Once the Eden area is GC, it will be empty！

2. In order to ensure that the to area is clean, the copy algorithm moves the objects in the form to to, and after copying, the two identities are exchanged immediately, dynamically

3. When an object has undergone 15 (default) GCs and has not died, it will enter the old age. , the default times can be modified

-XX: -XX:MaxTenuringThreshold=20 (jvm heap memory tuning) This parameter can be used to set the time to enter the old age

Movement of surviving objects while demonstrating GC

During the first GC, the ones that survived from Eden will go into to, and those from from will also be copied into to.

The result after this GC: Eden becomes empty, from and to identities are swapped

That is, the Eden and to areas are empty after each garbage collection.

Assuming that from is full and the number of times is reached, it will go to the old age

Pros and cons of replication algorithm:

• Benefit: no fragmentation of memory
• Disadvantage: waste of memory space (more than half of the space is always empty to). Assuming that the object is 100% alive (extreme case), in this case the cost of the replication algorithm is relatively high

The best usage scenario of the replication algorithm: when the object survival rate is low (the new area), the replication algorithm is used in the new area

Mark Sweep Algorithm

Make a mark on the surviving object, and clean up the unmarked object

The mark occupies memory, there are gaps after clearing, and the time consumption of two scans

• Pros: No extra space required (destroys the downside of the copy algorithm)
• Disadvantages: Two scans, a serious waste of time and memory fragmentation.

tag compression

Optimize the problem of memory fragmentation.

Compression: Prevents memory fragmentation. Scan again, moving live objects to one end, but with a time cost.

mark-sweep compression algorithm

mark clear compression

First clean the markup a few times, this will generate a lot of debris,

then use compression

This will save a little time and cost

Summarize

Memory Efficiency: Copy Algorithm > Mark Sweep Algorithm > Mark Compression Algorithm (Time Complexity)

Memory Uniformity: Copy Algorithm = Mark Compression Algorithm > Mark Clear Algorithm

Memory Utilization: Mark Compression Algorithm = Mark Sweep Algorithm > Copy Algorithm

Consider a question: Is there no optimal algorithm?

Answer: No, there is no best algorithm, only the most suitable algorithm. soGC: Generational Collection Algorithm

which isyoung generationBecause the object survival rate is low, it is suitable for usereplication algorithm。

andold ageBecause the area is large and the survival rate is high, it is suitable for useMarker Clear + Marker Compression Hybrid accomplish,

It involves tuning, and in the case of ensuring that the memory fragmentation is not too much, it will be compressed again after reaching an order of magnitude.
