LLDB debugging third-party app

First create a new project using xcode to connect to the mobile phone to debug it, so that there will be a debugserver program on the mobile phone, as shown in the figure.
LLDB app
It will be as shown in / Developer / usr / bin.

Because he cannot debug other apps at present, because he does not have task_for_pid permission. Copy it to the computer first.
Create a pist file in the same directory. as the picture shows.

entitlements.plist

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/ PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
    <key>com.apple.springboard.debugapplications</key> <true/>
    <key>run-unsigned-code</key>
    <true/>
    <key>get-task-allow</key>
    <true/>
    <key>task_for_pid-allow</key>
    <true/>
</dict>
</plist>

Sign it again.
codesign -s - --entitlements entitlements.plist -f debugserver
LLDB app
Upload to your phone / usr / bin. Select a process to debug it as shown.

forwarding port on mac
iproxy 1234 1234
Finally connect. Enter lldb to enter ldb, enter process connect connect: // localhost: 1234
Check the module and load base address at the same time.

View the debug stack.

Reprinted at: https://blog.51cto.com/haidragon/2396785
