1.readyapi installation operating environment

• IP：10.200.200.200

• table of Contents

  • Installation path /usr/local/readyapi2.3.0

  • Project path /home/readyapi/project

  • Jar package path /home/readyapi/ext

  • Scripts library path /home/readyapi/scripts

  • Log file path /home/readyapi/logs

  • Custom configuration file path /home/readyapi/config

  • Tomcat installation path /usr/local/apache-tomcat-9.0.12 (used to demonstrate automated execution reports)

2. Create a node on jenkins

• Configure node slave information, IPsh: 10.200.200.200

3. Install readyapi on the jenkins-node server

sh ReadyAPI-x64-2.3.0.sh -q -dir "/usr/local/readyapi2.3.0"

-q: install no UI application

-dir: specifies the application installation path, the default path User-Folder/SmartBear/ReadyAPI-version

• Installation package download address:

  https://support.smartbear.com/downloads/readyapi/?_ga=2.211948628.1939736508.1536911258-202716233.1527820141

  • Installation command

• sh ReadyAPI-x64-2.3.0.sh -q -dir "/usr/local/readyapi2.3.0"

  • There is a bug in the 2.4.0 version that cannot run the composite project, so choose to install version 2.3.0.

4. Copy the certificate KEY

• Permanent certificate

  Unused

• Trial certificate

  Copy the trial certificate key file soapui.key on the window to /root/.soupui/soapui.key

  (The current user is root, the install user is root, all .soapui and .readyapi are in the /root/ directory)

5. Copy the readypi project to the jenkins-node server

• Create 1 normal jenkins job-pull code

  • Pull the readyapi project code on git

  • Scp to the server where jenkins-node is located

scp -r /root/.jenkins/workspace/autotest/* [email protected]:/home/readyapi/project/auto-api-riskcontrol-readyapi

6. Run the readyapi project

• Modify the startup parameters of testrunner.sh

  Specify ext libarary

JAVA_OPTS="-Xms128m -Xmx$READY_XMX -Dtest.history.disabled=true -Dsoapui.properties=soapui.properties -Dgroovy.source.encoding=iso-8859-1 -Dsoapui.home=$READY_API_HOME/bin -Dsoapui.ext.libraries=/home/readyapi/ext -Dsun.jnu.encoding=UTF-8 -Dfile.encoding=UTF-8"

• Automate test projects with testruuner.sh

cd /home/readyapi

/usr/local/readyapi2.3.0/bin/testrunner.sh -Dsoapui.log4j.config="/home/readyapi/config/soapui-log4j.xml" -r -a -j -f/usr/local/apache-tomcat-9.0.12/webapps/report "-RJUnit-Style HTML Report" -FXML -Eautotest "/home/readyapi/project/auto-api-riskcontrol-readyapi" &

• Parameter Description

  • -Dsoapui.log4j.config can load a custom log4j log configuration file

  • -r: Commands the runner to include a summary report into the test log.

  • -a: Commands the runner to export all test results. Otherwise, it exports only information about errors.

  • -f/usr/local/apache-tomcat-9.0.12/webapps/report : Generate report storage address, here is the address of tomcat installation, directly generated into the tomcat application

  • -RJUnit-Style HTML Report" : Report Data Form

  • -FXML : report format

  • -Eautotest : Specify the use of the environment

  • "/home/readyapi/project/auto-api-riskcontrol-readyapi" : here is the file for the composite project

7. Configure the job running testrunner

• Set the node created for step 2

• Set the job's trigger event to "job task completion on git pull code"

• In order to make the jenkins job run, the testrunner can continue to execute. The first line in the shell needs to be declared.

  BUILD_ID="dontKillMe"



8. View the report

Start tomcat

Report url http://10.200.200.200:8080/report/



**problem**

1) When you are scp, you need to enter a password.

    scp A to B，

Establish B-to-A trust, secret-free login, use the keygen command on A to generate the public and private keys, and append the public key to B's ~/.ssh/authorized_keys file.

After the trust is established, the secret-free login still does not take effect, so the colleague of the operation and maintenance needs to help.

2). readyapi2.4.0 version can not run composite project error message

    [CompositeProjects] The file has not been loaded, because the project does not contain it

Reason: readyapi2.4.0 can't run the composite project, it is a bug of version 2.4.0.

Workaround: Run the composite project using readyapi version 2.3.0

3). Run the project can not find the class library ext lib

Modify the parameters of testrunner.sh and specify -Dsoapui.ext.libraries=/home/readyapi/ext

4). Run the project can not find the custom script

Readyapi is the runtime, find the script folder under the current path, and load all the custom scripts, so the cd to the upper directory of the script can be solved at runtime.

5). groovy script reads files, file separators window and linux are different
needs to be replaced with a system separator to ensure that the file can be found
