High-performance image algorithms usually use GPU acceleration, and the cuda module in OpenCV provides commonly used algorithm functions that can be run directly in the GPU. For complex applications, the functions in the cuda module cannot meet the requirements. In this case, you need to write your own cuda kernel.

The following code is an example of accessing OpenCV's data structure cv::cuda::Gpumat in the cuda kernel:

#include <cuda_runtime.h>
#include <opencv2/opencv.hpp>
#include <opencv2/core.hpp>
#include <opencv2/cudaarithm.hpp>


__global__ void Kernel_CalPhase2D(const cv::cuda::PtrStepSzf dReal, const cv::cuda::PtrStepSzf dImag,
                                      const float d_Pi, cv::cuda::PtrStepSzf dOutput)
{
    int iCol = blockIdx.x * blockDim.x + threadIdx.x; int iRow = blockIdx.y * blockDim.y + threadIdx.y;

    if (iCol < dReal.cols && iRow < dReal.rows && iRow >= 0 && iCol >= 0)
    {
        dOutput(iRow, iCol) = (atan2(dImag(iRow, iCol), dReal(iRow, iCol)) * (-1) + d_Pi) / (2 * d_Pi);
    }
}

void CalculatePhase2D(const cv::InputArray _input0, const cv::InputArray _input1, cv::OutputArray _output)
{
    const cv::cuda::GpuMat input0 = _input0.getGpuMat();
    const cv::cuda::GpuMat input1 = _input1.getGpuMat();

    _output.create(input0.size(), input0.type());

    cv::cuda::GpuMat output0 = _output.getGpuMat();

    dim3 cthreads(32, 32);
    dim3 cblocks(
                static_cast<int>(std::ceil(input0.size().width /
                                           static_cast<double>(cthreads.x))),
                static_cast<int>(std::ceil(input0.size().height /
                                           static_cast<double>(cthreads.y))));

    Kernel_CalPhaseInfo2D << <cblocks, cthreads >> > (input0, input1, 3.14159f, output0);

    if (cudaSuccess != cudaGetLastError())
        std::cout << "CalculatePhaseInfo2D(): gave an error" << std::endl;

    return;
}
