[OpenCV3] Detailed use of cv::convertScaleAbs()

cv::convertScaleAbs() is used to implement the following operations for each element in the entire image array:

This operation can realize the fast calculation of image enhancement and other related operations. The specific usage is as follows:

void cv::convertScaleAbs(
	cv::InputArray src, // input array
	 cv::OutputArray dst, // output array
	 double alpha = 1.0, // multiplier factor
	 double beta = 0.0 // offset
);

The following uses a specific example to demonstrate the magical use of this function:

	cv::Mat src = cv::imread("img0.jpg", -1);
	cv::Mat dst;

	cv::convertScaleAbs(src, dst, 1.5, 10);

	cv::imshow("src", src);
	cv::imshow("dst", dst);

	cv::waitKey(0);

	return;

The results are as follows:

2018.08.12
