First, basically

1, GRPC definition

A High-Performance, Open-Source Universal RPC Framework: High Performance, Open Source Universal RPC Framework

The so-called RPC (Remote Procedure Call Remote Process Call) framework is actually provided a mechanism that can be communicated between the applications, and also follow the Server / Client model. When using it, the client calls the server-connected interface is like calling a local function.



2、grpc VS restful api

Both GRPC and RESTFUL API provide a set of communication mechanisms for server / client model communication, and they all use HTTP as the underlying transport protocol (strictly said that the HTTP2.0 used by GRPC, and the Restful API is not necessarily) .

• GRPC can define the interface through Protobuf, so that there can beMore stringent interface constraints。

• In addition, data sequence can be serialized through ProtobufBinary codeThis will greatly reduce the amount of data that needs to be transmitted, thereby greatly improves performance.

• GRPC can easily supportStreamCommunication (theoretically via HTTP2.0 can use Streaming mode, but usually the RESTful API of the web service seems to be so useful, usually flow data applications such as video streams, generally use specializes such as HLS, RTMP, etc. It's not us usually web service, but there is a dedicated server application.)



3, GRPC usage scene

• The case where the interface is strictly constrained, especially the factors considering safety
• For performance, there is a higher demand. Need to pass a large number, asynchronous requests pass binary data



4、protobuf

4.1 definition

Protobuf is actually a data transfer format and specification similar to JSON or XML, which is used when communicating between different applications or processes. The information transmitted during communication is packed by the Message data structure defined by Protobuf, and then compiled into binary code streams and then transmits or stores.



4.2 Advantages

In contrast, Protobuf has the following advantages:

• Simple enough
• After serialization, the volume is small: the message size only needs 1/10 ~ 1/3 of XML
• Resolution speed: Analytical speed is 20 ~ 100 times faster than XML
• Multilingual support
• Better compatibility, a principle of protobuf design is to be able to support down or upwardly



5. Relationship between protoc, protoc-gen-go and grpc

5.1 protoc

The protoc command comes from https://github.com/golang/protobuf, which can generate serialization and reverse selecente code, without Go-related code.

Protoc is a compiler of the protobuf file (.proto), with it to translate the .proto file into a source code corresponding to a variety of programming languages.

Compilation method
 protoc --go_out=./go1/ ./proto/my.proto

Protoc's version can be viewed through Protoc --Version



5.2 protoc-gen-go

Protoc-gen-GO plug-in, from https://github.com/golang/protobuf/protoc-gen-go, you can generate GO-related code, in addition to the above serialization and reverse sequence code, add some communication public Library. It is a Go version in the Protobuf compilation plugin series

Compilation method
  protoc --go_out=plugins=grpc:./go2/  ./proto/my.proto



5.3 grpc

GRPC comes from https://google.golang.org/grpc or https://github.com/grpc/grpc-go ,Protoc and protoc-gen-go These two tools are not there, The protoc and protoc-gen-g are needed to be placed in the system PATH.



Second, install

1, download Protobuf, install protoc

Method 1: Download binary directly

Download address: https://github.com/protocolbuffers/protobuf/releases

Download the corresponding OS compression package to decompress,binYou can see the compiled Protoc, you can use it in the system PATH.

Method Two:

Download the source code slowly compile, but I won't hahahahaha



2, install GRPC

Project address: https://github.com/grpc/grpc


2.1 Using the official installation command

go get google.golang.org/grpc

But it will report an error: (I will not go online.

package google.golang.org/grpc: unrecognized import path “google.golang.org/grpc”(https fetch: Get https://google.golang.org/grpc?go-get=1: dial tcp 216.239.37.1:443: i/o timeout)



2.2 Installing using gitclone

git clone https://github.com/grpc/grpc-go.git $GOPATH/src/google.golang.org/grpc
git clone https://github.com/golang/net.git $GOPATH/src/golang.org/x/net
git clone https://github.com/golang/text.git $GOPATH/src/golang.org/x/text

cd $GOPATH/src/
go install google.golang.org/grpc

go installThe deficiencies are gitclone



3, install protoc-gen-go

3.1 download installation

go get -u github.com/golang/protobuf/protoc-gen-go

exist$GOPATH/binGo down to generate corresponding binary



3.2 Use the command description

protoc --go_out=output_directory input_directory/file.proto

Where "-go_out =" means generating a Go file, Protoc automatically looks for the Protoc-Gen-GO execution file in the PATH (system execution path).



3.3 Install the specified version

If you need to download the specified version of Protoc-Gen-Go, then: (Version in version can passGit Checkout [Tab Key]Add it to see what

cd "$(go env GOPATH)"/src/github.com/golang/protobuf
VERSION=v1.5.0
git checkout $VERSION
cd protoc-gen-go
go install

The generated binary will also be placed$GOPATH/binMiddle (remember$GOPATH/binJoin the system path, otherwise you can find it when using protoc




Reference link:
https://www.jianshu.com/p/dba4c7a6d608
https://blog.csdn.net/stpeace/article/details/82713647
https://studygolang.com/articles/12673?fr=sidebar

If there is something wrong, please point out, thank you ~
