The second task of the internship is to convert RGB pictures to NV21 (a storage format of YUV, which is also the most common raw storage format for pictures in Android phones)

Let's take a look at NV21 and other similar storage formats~

Introduction of NV21 (YUV420)
NV12 and NV21 belong to the YUV420 format (four Y per 2x2, sharing a group of uv), is a two-plane mode, that is, Y and UV are divided into two Plane, but CbCr) is interleaved storage, rather than divided into three planes. Store all Y first, then UV staggered storage: NV12 first U then V, NV21 first V then U.

The example format of YUV420sp is as follows:

NV21：

NV12：

It can be seen that the storage format of NV21 and NV12 is the separation of Y component and U and V components, not the storage format like RBG storage format.

The function that I realized is to store the RGB format picture as the binary format of NV21, and then use the software specifically designed to open YUV-7YUV to open the file.

Come to Kang Kang effect first~


Open the pictures stored in NV21 with opencv:

The gray space below is the manifestation of U and V components under opencv

The rendering after opening with 7YUV software:

The specific code implementation is as follows:

#include <iostream>
#include <opencv2/core/core.hpp>
#include <opencv2/highgui/highgui.hpp>
#include <opencv2/imgproc/imgproc.hpp>
#include <vector>
#include <fstream>
#include <string>

void RGB2NV21()
{
	const char *filename = "yuv.yuv";
	cv::Mat Img = cv::imread("RGB.jpg");
	FILE  *fp = fopen(filename,"wb");

	if (Img.empty())
	{
		std::cout << "empty!check your image";
		return;
	}
	int cols = Img.cols;
	int rows = Img.rows;

	int Yindex = 0;
	int UVindex = rows * cols;

	unsigned char* yuvbuff = new unsigned char[1.5 * rows * cols];

	cv::Mat NV21(rows+rows/2, cols, CV_8UC1);
	cv::Mat OpencvYUV;
	cv::Mat OpencvImg;
	cv::cvtColor(Img, OpencvYUV, CV_BGR2YUV_YV12);

	int UVRow{ 0 };
	for (int i=0;i<rows;i++)
	{
		for (int j=0;j<cols;j++)
		{
			uchar* YPointer = NV21.ptr<uchar>(i);

			int B = Img.at<cv::Vec3b>(i, j)[0];
			int G = Img.at<cv::Vec3b>(i, j)[1];
			int R = Img.at<cv::Vec3b>(i, j)[2];

			//Calculate the value of Y
			int Y = (77 * R + 150 * G + 29 * B) >> 8;
			YPointer[j] = Y;
			yuvbuff[Yindex++] = (Y < 0) ? 0 : ((Y > 255) ? 255 : Y);
			uchar* UVPointer = NV21.ptr<uchar>(rows+i/2);
			 //Calculate the values ​​of U and V, and sample 2x2
			if (i%2==0&&(j)%2==0)
			{
				int U = ((-44 * R - 87 * G + 131 * B) >> 8) + 128;
				int V = ((131 * R - 110 * G - 21 * B) >> 8) + 128;
				UVPointer[j] = V;
				UVPointer[j+1] = U;
				yuvbuff[UVindex++] = (V < 0) ? 0 : ((V > 255) ? 255 : V);
				yuvbuff[UVindex++] = (U < 0) ? 0 : ((U > 255) ? 255 : U);
			}
		}
	}
	for (int i=0;i< 1.5 * rows * cols;i++)
	{
		fwrite(&yuvbuff[i], 1, 1, fp);
	}
	fclose(fp);
	std::cout << "write to file ok!" << std::endl;
	std::cout << "srcImg: " << "rows:" << Img.rows << "cols:" << Img.cols << std::endl;
	std::cout << "NV21: " << "rows:" << NV21.rows << "cols:" << NV21.cols << std::endl;
	std::cout << "opencv_YUV: " << "rows:" << OpencvYUV.rows << "cols:" << OpencvYUV.cols << std::endl;

	 cv::imshow("src", Img);//Original picture
	 cv::imshow("YUV", NV21);//The converted picture
	 cv::imshow("opencv_YUV", OpencvYUV); //Opencv converted picture
	cv::imwrite("NV21.jpg", NV21);
	cv::waitKey(30000);
}

int main()
{
	RGB2NV21();
	return 0;
}

The above is the whole content of RBG to NV21
