useCMakeIt is easy to implement cross-platform compilation. If you want to link a third-party library, you need to set it up for the platform. Here is how to create a simple CMake project to realize automatic compilation on Windows, Linux and macOS.

SDK download

• Dynamsoft Barcode Reader 5.2 for Windows
• Dynamsoft Barcode Reader 5.2 for Linux
• Dynamsoft Barcode Reader 5.2 for macOS

CMake download and install

Windows

• Visual Studio Community 2017
• cmake-3.9.5-win64-x64.msi

Linux

sudo apt-get install cmake

macOS

brew install cmake

Be careful not tobrewAdd beforesudo. NewestbrewNo longer supported, an error will occur if used:

Error: Running Homebrew as root is extremely dangerous and no longer supported.
As Homebrew does not drop privileges on installation you would be giving all
build scripts full access to your system.

Engineering structure

project
    |-- platforms
        |-- win
            |-- DBRx86.lib
            |-- DynamsoftBarcodeReaderx86.dll
        |-- linux
            |-- libDynamsoftBarcodeReader.so
        |-- macos
            |-- libDynamsoftBarcodeReader.dylib
    |-- include
        |-- DynamsoftBarcodeReader.h
    |-- BarcodeReader.cxx
    |-- BarcodeReaderConfig.h.in
    |-- CMakeLists.txt

C++ code

Wrote a simple command line barcode reader. The focus here is how to configure CMake, the code does not explain.
can browseBarcodeReader.cxx

CMakeLists.txt

Platform distinction

if (CMAKE_HOST_WIN32)
    set(WINDOWS 1)
elseif(CMAKE_HOST_APPLE)
    set(MACOS 1)
elseif(CMAKE_HOST_UNIX)
    set(LINUX 1)
endif()

Set the dynamic link library path

if(WINDOWS)
    link_directories("${PROJECT_SOURCE_DIR}/platforms/win")
elseif(LINUX)
    link_directories("${PROJECT_SOURCE_DIR}/platforms/linux")
elseif(MACOS)
    link_directories("${PROJECT_SOURCE_DIR}/platforms/macos")
endif()

Copy the dll file to the output directory on Windows

if(WINDOWS)
    # Copy DLL files to output directory
    if(CMAKE_CL_64)
        add_custom_command(TARGET BarcodeReader POST_BUILD
        COMMAND ${CMAKE_COMMAND} -E copy_if_different
        "${PROJECT_SOURCE_DIR}/platforms/win/DynamsoftBarcodeReaderx64.dll"
        $<TARGET_FILE_DIR:BarcodeReader>)
    else()
        add_custom_command(TARGET BarcodeReader POST_BUILD
        COMMAND ${CMAKE_COMMAND} -E copy_if_different
        "${PROJECT_SOURCE_DIR}/platforms/win/DynamsoftBarcodeReaderx86.dll"
        $<TARGET_FILE_DIR:BarcodeReader>)
    endif()
endif()

Set installation path

if(WINDOWS)
    set(CMAKE_INSTALL_PREFIX "e:/${PROJECT_NAME}")
    if(CMAKE_CL_64)
    install (FILES "${PROJECT_SOURCE_DIR}/platforms/win/DynamsoftBarcodeReaderx64.dll" DESTINATION bin)
    else()
    install (FILES "${PROJECT_SOURCE_DIR}/platforms/win/DynamsoftBarcodeReaderx86.dll" DESTINATION bin)
    endif()
elseif(LINUX)
    install (FILES "${PROJECT_SOURCE_DIR}/platforms/linux/libDynamsoftBarcodeReader.so" DESTINATION lib)
elseif(MACOS)
    install (FILES "${PROJECT_SOURCE_DIR}/platforms/macos/libDynamsoftBarcodeReader.dylib" DESTINATION lib)
endif()

On Windows, it will be installed to the C drive by default. If the command line tool does not have administrator rights, the installation will fail. So you can change the default installation path.

Set RPATH

# Set RPATH
if(WINDOWS)
else()
    set(CMAKE_INSTALL_RPATH "${CMAKE_INSTALL_PREFIX}/lib")
    MESSAGE( STATUS "CMAKE_INSTALL_RPATH: " "${CMAKE_INSTALL_PREFIX}/lib" )
    set(CMAKE_INSTALL_RPATH_USE_LINK_PATH TRUE)
endif()

The default path on Linux and macOS is /usr/local. After installation, the execution program will not find the dynamic link library. After setting RPATH, there will be no problems.

Compile and install the project

Generate project files:

mkdir build
cd build
cmake ..

X86 is the default on Windows. If you want to use x64, you need to specify the generator:

cmake -G"Visual Studio 14 2015 Win64" ..

Compile and install:

cmake --build . --target install

When using commands on Linux, addsudo。

Full CMakeLists.txt

cmake_minimum_required (VERSION 2.6)
project (BarcodeReader)
MESSAGE( STATUS "PROJECT_NAME: " ${PROJECT_NAME} )

# The version number.
set(BarcodeReader_VERSION_MAJOR 1)
set(BarcodeReader_VERSION_MINOR 0)

# Check platforms
if (CMAKE_HOST_WIN32)
    set(WINDOWS 1)
elseif(CMAKE_HOST_APPLE)
    set(MACOS 1)
elseif(CMAKE_HOST_UNIX)
    set(LINUX 1)
endif()

# Set RPATH
if(WINDOWS)
else()
    set(CMAKE_INSTALL_RPATH "${CMAKE_INSTALL_PREFIX}/lib")
    MESSAGE( STATUS "CMAKE_INSTALL_RPATH: " "${CMAKE_INSTALL_PREFIX}/lib" )
    set(CMAKE_INSTALL_RPATH_USE_LINK_PATH TRUE)
endif()

# Configure a header file to pass some of the CMake settings
# to the source code
configure_file (
    "${PROJECT_SOURCE_DIR}/BarcodeReaderConfig.h.in"
    "${PROJECT_BINARY_DIR}/BarcodeReaderConfig.h"
)

# Add search path for include and lib files
if(WINDOWS)
    link_directories("${PROJECT_SOURCE_DIR}/platforms/win")
elseif(LINUX)
    link_directories("${PROJECT_SOURCE_DIR}/platforms/linux")
elseif(MACOS)
    link_directories("${PROJECT_SOURCE_DIR}/platforms/macos")
endif()
include_directories("${PROJECT_BINARY_DIR}" "${PROJECT_SOURCE_DIR}/include")

# Add the executable
add_executable(BarcodeReader BarcodeReader.cxx)
if(WINDOWS)
    if(CMAKE_CL_64)
        target_link_libraries (BarcodeReader "DBRx64")
    else()
        target_link_libraries (BarcodeReader "DBRx86")
    endif()
else()
    target_link_libraries (BarcodeReader "DynamsoftBarcodeReader")
endif()

if(WINDOWS)
    # Copy DLL files to output directory
    if(CMAKE_CL_64)
        add_custom_command(TARGET BarcodeReader POST_BUILD
        COMMAND ${CMAKE_COMMAND} -E copy_if_different
        "${PROJECT_SOURCE_DIR}/platforms/win/DynamsoftBarcodeReaderx64.dll"
        $<TARGET_FILE_DIR:BarcodeReader>)
    else()
        add_custom_command(TARGET BarcodeReader POST_BUILD
        COMMAND ${CMAKE_COMMAND} -E copy_if_different
        "${PROJECT_SOURCE_DIR}/platforms/win/DynamsoftBarcodeReaderx86.dll"
        $<TARGET_FILE_DIR:BarcodeReader>)
    endif()
endif()

# Set installation directory
if(WINDOWS)
    set(CMAKE_INSTALL_PREFIX "e:/${PROJECT_NAME}")
    if(CMAKE_CL_64)
    install (FILES "${PROJECT_SOURCE_DIR}/platforms/win/DynamsoftBarcodeReaderx64.dll" DESTINATION bin)
    else()
    install (FILES "${PROJECT_SOURCE_DIR}/platforms/win/DynamsoftBarcodeReaderx86.dll" DESTINATION bin)
    endif()
elseif(LINUX)
    install (FILES "${PROJECT_SOURCE_DIR}/platforms/linux/libDynamsoftBarcodeReader.so" DESTINATION lib)
elseif(MACOS)
    install (FILES "${PROJECT_SOURCE_DIR}/platforms/macos/libDynamsoftBarcodeReader.dylib" DESTINATION lib)
endif()

install (TARGETS BarcodeReader DESTINATION bin)
install (FILES "${PROJECT_BINARY_DIR}/BarcodeReaderConfig.h" DESTINATION include)
install (DIRECTORY "${PROJECT_SOURCE_DIR}/include" DESTINATION include)

# Use CTest
include(CTest)
add_test (BarcodeReaderRuns BarcodeReader)

Source code

https://github.com/dynamsoft-dbr/cmake
