FreeCAD import DWG
tags: Experience skills
problem
FreeCAD 0.17 cannot open .dwg file
The following prompt is displayed:
method
- Download ODA File Converter
- installation
The path after Ubuntu 18.04 installation is:usr/bin/ODAFileConverter - Configuration
Edit → Preferences → Import-Export → DWG→ “Path to Teigha File Converter”
- Use: After opening the .dwg file, the ODAFileConcerter interface will pop up automatically, and the file will be converted and opened in FreeCAD.
- If it can't be opened, check the path of ODAFileConcerter (windows needs to be configured to ODAFileConcerter.exe level). Or check the original file.
reference
https://www.freecadweb.org/wiki/FreeCAD_and_DWG_Import
https://www.opendesign.com/guestfiles/oda_file_converter
