Serial Port Interrupt transmission array data string and
This is a general framework, we first open the serial port, and then type the data into u8 u16 type of rec_data years. Note look behind the green word can be known 'S''E' respectively represent the start and end of the protocol identifier, the bottom is determined that said transmitted data bytes is performed is between 0 ~ UART3_REC_NUM.
That is our normal execution order if in the function, then a second one in the compound statement else if, else if finally first in the compound statement.
Now, I release the first and third compound statement
The first number of bytes in a compound statement, we accepted in the serial interrupt accumulate
The third compound statement, we will rec_data in data into receive_str [uart_byte_count-1]
Finally, we will execute the code in the second compound statement
We there are two control statements if (strcmp (A, B) == 0) LED0 = 0; That is, if // A, B can be performed the same as the following statement
The 'A' is converted to A ASCLL code string, and then determination.
