Foreword

FreeRADIUS is the GNU General Public License developed high-performance open source RADIUS server. FreeRADIUS is the world's most used on the RADIUS server. FreeRADIUS with a Web-based user management tool is a modular, scalable and rich feature set.

Note: This article All commands are done by the root command.

Install CentOS-7-X86_64-Minimal and configure a static IP here is not to describe (IP set to 192.168.1.211, behind this is to fill in the radius IP)

Before starting the installation, the proposed closure SELinux or set to disabled, the best advice is permanently closed SELinux:

# sed -i 's/^SELINUX=.*/SELINUX=disabled/g' /etc/selinux/config

Reboot the system: After reboot, reboot is complete view SELinux

Check firewall status, the state can start adding rules, centos7 default firewall is firewall

# firewall-cmd --state

Turn off the firewall and the firewall turned off the boot:

Directly off the firewall

# Systemctl stop firewalld.service

Prohibit firewall boot

# Systemctl disable firewalld.service



First, install the Apache server



1, the installation

# yum -y install httpd httpd-devel



2, set the boot and start the Apache service

# systemctl enable httpd

# systemctl start httpd

3, after starting the browser, enter the machine ip, you can see Apache Home



Second, install MariaDB

Why not Mysql?
A: MariaDB MySQL database management system is a branch, mainly by the open source community in the maintenance, under the GPL license. One reason for the development of this branch is: after Oracle's acquisition of MySQL, there are potential risks to MySQL closed source, so the branch community a way to avoid this risk.

1, the installation

# yum install -y mariadb-server mariadb

2, set the boot and start MariaDB MariaDB services

# systemctl start mariadb

# systemctl enable mariadb

3, see the MariaDB state, running is already running

# systemctl status mariadb

4, initial setting MariaDB, set the root password;

For security reasons, consider removing the anonymous user and disable remote root login, see the following sample configuration,

# mysql_secure_installation



Set root password? [Y/n] y

New password: Re-enter new password:

Password updated successfully! Reloading privilege tables..

... Success!

Remove anonymous users? [Y/n] y

Disallow root login remotely? [Y/n] y

Remove test database and access to it? [Y/n] y

Reload privilege tables now? [Y/n] y



5, Radius create the database and user name and password

# mysql -u root -p

MariaDB [(none)]> CREATE DATABASE radius;

MariaDB [(none)]> GRANT ALL ON radius.* TO radius@localhost IDENTIFIED BY "radius";

MariaDB [(none)]> FLUSH PRIVILEGES;

MariaDB [(none)]> exit



Third, the installation PHP7



1, the installation

# curl 'https://setup.ius.io/' -o setup-ius.sh

# bash setup-ius.sh

# yum remove php-cli mod_php php-common

# yum -y install mod_php70u php70u-cli php70u-mysqlnd php70u-devel php70u-gd php70u-mcrypt php70u-mbstring php70u-xml php70u-pear



2, view the php version

# php -v

3, the test PHP

New info.php page with the directory under the Apache website, after typing press Ins press esc,: wq save and exit.

# vi /var/www/html/info.php

Fill in the following test elements:

<?php phpinfo(); ?>

4, restart the Apache server

Open info.php page, php display information that is normal. IP / info.php

# systemctl restart httpd.service

Fourth, the installation FreeRadius

1, the installation

# yum -y install freeradius freeradius-utils freeradius-mysql

2, set the start radius and start-up

# systemctl start radiusd.service

# systemctl enable radiusd.service

3, configuration FreeRadius

3.1 Radius introduced into the database in the database maiadb

# mysql -u root -p radius < /etc/raddb/mods-config/sql/main/mysql/schema.sql

3.2, / raddb / mods-enabled to create a soft link to / etc

# ln -s /etc/raddb/mods-available/sql /etc/raddb/mods-enabled/

3.3, SQL module configuration / raddb / mods-available / SQL, and change the database connection parameters to fit the environment:

# vi /etc/raddb/mods-available/sql

sql {

# The sub-module to use to execute queries. This should match

# the database you're attempting to connect to.

#

# * rlm_sql_mysql

# * rlm_sql_mssql

# * rlm_sql_oracle

# * rlm_sql_postgresql

# * rlm_sql_sqlite

# * rlm_sql_null (log queries to disk)

driver = "rlm_sql_mysql"

dialect = "mysql"

# Connection info:

server = "localhost"

port = 3306

login = "radius"

password = "radius"

# Database table configuration for everything except Oracle

 radius_db = "radius"

 ......

# Set to 'yes' to read radius clients from the database ('nas' table) # Clients will ONLY be read on server startup.

read_clients = yes

Other no need to change the default configuration.

3.4, then the / etc / raddb / mods-enabled / sql owning group are changed radiusd:

# chgrp -h radiusd /etc/raddb/mods-enabled/sql



3.5, is added to start the service, and to adjust the boot sequence FreeRadius the MariaDB, FreeRadius MariaDB be started after startup, [Unit] section, increasing After = mariadb.service, as shown below:

# systemctl enable radiusd.service

# vi /etc/systemd/system/multi-user.target.wants/radiusd.service

After=mariadb.service

3.6, add a client connection settings, add all users are allowed access. For specific access ip, ip can be freely changed.

# vi /etc/raddb/clients.conf

client all_client {

ipaddr = 0.0.0.0/0

secret = testing123

require_message_authenticator = no

}

Fifth, install FreeRADIUS management interface Daloradius

1, into the Apache root of the site, download the source files

# cd /var/www/html/

# wget https://github.com/lirantal/daloradius/archive/master.zip



In case of -bash: wget: command not found, etc. to install the appropriate software, did not appear to ignore this step.

# yum -y install wget unzip zip

2, extracting archive, modify the folder name

# unzip master.zip

# mv daloradius-master/ daloradius



3, download daloradius-0.9-9.tar.gz, after extracting merged into daloradius folder

# wget http://liquidtelecom.dl.sourceforge.net/project/daloradius/daloradius/daloradius0.9-9/daloradius-0.9-9.tar.gz

# unzip master.zip

# mv daloradius-master/ daloradius



4, enter daloradius directory, database import daloradius

# cd daloradius

# mysql -u root -p radius < contrib/db/fr2-mysql-daloradius-and-freeradius.sql

# mysql -u root -p radius < contrib/db/mysql-daloradius.sql



5, set daloradius directory user groups and users, set permissions daloradius.conf.php

# chown -R apache:apache /var/www/html/daloradius/

# chmod 664 /var/www/html/daloradius/library/daloradius.conf.php



6, a connection information database daloradius

Open daloradius.conf.php file, modify CONFIG_DB_USER, CONFIG_DB_PASS, CONFIG_DB_NAME.

# vi /var/www/html/daloradius/library/daloradius.conf.php

7, restart the service



# systemctl restart radiusd.service

# systemctl restart mariadb.service

# systemctl restart httpd



If the prompt: Warning:. Radiusd.service changed on disk Run 'systemctl daemon-reload' to reload units

The above tips will not ignore this step

# systemctl daemon-reload

# systemctl restart radiusd.service



8, installed php-pear

# yum install php-pear

# pear install DB



9, login the web interface

default user name: administrator
Password: radius

http://ip-address/daloradius/login.php

Create a user after logging in Management wisoft for testing



So far FreeRadius + Daloradius + web management interface has been installed successfully

Six test

Radiustest use third-party testing tools to verify that the server installation was successful, successful interface is as follows, accessories

Seven, AP router settings

(Firmware ASUS RT-N56U)

Reset After resetting the device, enter the management pagehttp://192.168.123.1/



1, change the routing operation mode to AP mode

2, is provided a RADIUS 2.4GHz wireless set

3, set up a wireless network License



Reference Bowen:

Official website:

http://daloradius.com/

There's one virtual machine, not tested
