Implementation of HDMI (DVI) Receiver with Xilinx FPGA

1. Problem-HDMI receiver

1.1 ADV7511

Generally speaking, if you want to use HDMI as a video transceiver protocol, you will configure the HDMI codec chip. Common ones are ADV7511 (HDMI transmitter) and ADV7611 (HDMI receiver). In this way, the HDMI design part of the developer can be transformed into data interaction with the HDMI receiving or transmitting chip. When designing with FPGAs, some FPGAs have HDMI interfaces but not HDMI codec chips. How to use HDMI interface at this time?
One solution is to use an external HDMI module daughter card through the FMC interface, so that the HDMi codec chip can be used. Alternatively, you can use the HDMi IP built into the FPGA. Next I will introduce the realization of HDMI receiver using Xilinx IP.
For the HDMI transmitter part, of course, Xilinx IP can also be used.

2. HDMI (DVI) receiver

2.1 IP settings

This article uses the genesys2 development board of Digilent, and the IP provided by Digilent. It should be noted here that when you install vivado, the IP of Digilent will not be integrated into the IP of vivado. You need to download it manually by the developer and add it to vivado.

2.2 IP settings are as follows

First, set the operating frequency of TMDS. The most important thing is to enable Enable DDC ROM, which will set the resolution acceptable to the DVI receiver. When connected to the DVI transmitter, the transmitter will automatically read the resolution that the receiver can handle from the receiver. Send data at this resolution. If the Enable DDC ROM is not enabled, the sender will not be able to detect the HDMI receiver and cannot send data.

3. HDMI to VGA

The following code is a simple HDMI-VGA converter. After the FPGA is set up, connect it to the PC, and then connect the FPGA to a VGA display. The picture information will be sent from the PC and displayed on the VGA display via the FPGA.

```handlebars
module  hdmi_input(
input             clk_in1_n,
input             clk_in1_p,
input  			  sys_rst,		//High level reset

//dvi interface
  input TMDS_Clk_p,
  input TMDS_Clk_n               ,
  input [2:0]TMDS_Data_p         ,
  input [2:0]TMDS_Data_n         ,
    inout   DDC_0_scl_io,
  inout    DDC_0_sda_io,
  output   hpa,

  output   led1                  ,
	output				vga_hsync,
	output				vga_vsync,
	output[4:0]			vga_r,
	output[5:0]			vga_g,
	output[4:0]			vga_b

);

wire  rst;
wire     clk_200m;
wire     locked;
assign  hpa = 1;
wire SDA_I ;
wire SDA_O ;
wire SDA_T ;
wire SCL_I ;
wire SCL_O ;
wire SCL_T ;

wire [23:0]vid_pData;
wire vid_pVDE;
wire  vid_pHSync;
wire  vid_pVSync;
  wire  PixelClk;
  wire  aPixelClkLckd;
reg   pRst;

reg [10:0]   hcnt;
reg [9:0]    ycnt;
sys_rst_hdmi     u_sys_rst(
.rst       (rst),
.sys_rst   (!locked & sys_rst),
.clk       (clk_200m)
    );

clk_hdmi   u_clk_hdmi(
  .clk_200m            (clk_200m)  ,
  .reset               (sys_rst)   ,
  .locked              (locked)    ,
  .clk_in1_p           (clk_in1_p) ,
  .clk_in1_n           (clk_in1_n)
  );
  IOBUF DDC_0_scl_iobuf
       (.I(SCL_O),
        .IO(DDC_0_scl_io),
        .O(SCL_I),
        .T(SCL_T));
  IOBUF DDC_0_sda_iobuf
       (.I(SDA_O),
        .IO(DDC_0_sda_io),
        .O(SDA_I),
        .T(SDA_T));
dvi2rgb_0  u_dvi2rgb(
  .TMDS_Clk_p                       (TMDS_Clk_p),
  .TMDS_Clk_n                       (TMDS_Clk_n),
  .TMDS_Data_p                      (TMDS_Data_p),
  .TMDS_Data_n                      (TMDS_Data_n),
  .RefClk                           (clk_200m),
  .aRst                             (rst),
  .vid_pData                        (vid_pData),    //Output Data
  .vid_pVDE                         (vid_pVDE),     //Data valid enable signal
  .vid_pHSync                       (vid_pHSync),
  .vid_pVSync                       (vid_pVSync),
  .PixelClk                         (PixelClk),
  .aPixelClkLckd                    (aPixelClkLckd),
  .SDA_I                            (SDA_I),
  .SDA_O                            (SDA_O),
  .SDA_T                            (SDA_T),
  .SCL_I                            (SCL_I),
  .SCL_O                            (SCL_O),
  .SCL_T                            (SCL_T),


  .pRst								(pRst)
);
always@(posedge PixelClk)
begin
     pRst <=  rst;
end
assign vga_hsync = vid_pHSync;
assign vga_vsync = vid_pVSync;
assign vga_r  = vid_pData[23:19];
 assign      vga_g  = vid_pData[15:10];
 assign      vga_b  = vid_pData[7:3];

endmodule
