Spring Cloud builds an enterprise-level bus-part 8 message bus
Preface
Let me recap first. In the previous introduction of spring Cloud Config, we still left a suspense: how to achieve real-time update of configuration information. Although we have been able to pass the /refresh interface, if all trigger operations require us to maintain the application location manually, this will become more and more difficult to maintain with the continuous expansion of the system, and the message broker middleware is the solution The most suitable solution to this problem, the message broker middleware can route the message to one or more destinations. Using this function, we can perfectly solve the problem. Let's talk about the specific implementation scheme in Spring Cloud Bus.Principle analysis
We use the integration of Spring Cloud Bus and Spring Cloud Config, and use Kafka as the message broker to dynamically update the application configuration.
The architecture of the entire solution is shown in the figure above, which contains three instances of Svn warehouse, Config Server, and microservice "Service A". All three instances have introduced Spring Cloud Bus, so they are all connected to Kafka messages On the bus.
When we start the system, the three instances of "Service A" will request the Config Server to obtain configuration information. The Config Server obtains the configuration information from the Svn warehouse and returns it according to the rules of the application configuration.
At this point, if we need to modify the attributes of "Service A". First, use the Svn management tool to modify the corresponding attribute value in the warehouse, but this modification will not trigger the attribute update of the "Service A" instance. We send a POST request to instance 3 of "Service A" to access the /bus/refresh interface. At this point, instance 3 of "Service A" will send a refresh request to the message bus, and the message event will be retrieved from the bus by instance 1 and instance 2 of "Service A", and get them from the Config Server again The configuration information to realize the dynamic update of configuration information.
Use case
ready
Let's try the whole configuration process in detail below:Preparatory work: We are not doing new applications here, but we need to use the several projects about Spring Cloud Config that we have implemented in the previous chapter. If readers don't understand them yet, it is recommended to read Chapter 6 first.
- cloudConfig: A directory defined in the Svn warehouse, which stores a multi-environment configuration file named didispace, with a from parameter in the configuration file.
- config-server-eureka: Configure the Svn warehouse and register it to the Eureka server.
- config-client-eureka: Discover the client of Config Server through Eureka. The application name is didispace, which is used to access the configuration server to obtain configuration information. The application provides a /from interface, which will get the from property in \cloudConfig\config-repo\didispace.properties and return it.
Integrate Spring Cloud Bus
If we want to use Kafka to implement the message bus, we only need to modify the spring-cloud-starter-bus-kafka module in the dependenies node of pom.xml, as follows:
<dependency>
<groupId>org.springframework.cloud</groupId>
<artifactId>spring-cloud-starter-bus-kafka</artifactId>
</dependency>When the config-server starts, we can see the following output in the console:
At this point, we can use the kafka-topics --list --zookeeper localhost:2181 command to view the topics in the current Kafka. If the config-server has been successfully started and configured correctly, we can see that there are more in Kafka A topic called springCloudBus.
We then start the config-client configured with the spring-cloud-starter-bus-kafka module, and you can see the following output in the console:
You can see that similar content is output when the config-client is started, and they all subscribe to the topic named springCloudBus.
After starting config-server and config-client, in order to observe the effect of message bus refresh configuration more clearly, we can start multiple config-clients with different ports locally. At this point, our config-server and multiple config-clients have been connected to the message bus implemented by Kafka. We can first visit the /from request on each config-client to view the configuration content he obtained. Then, modify the corresponding parameter content in Svn, and then visit the /from request on each config-client, you can see that the configuration content has not changed. Finally, we send a POST request to the config-server: /bus/refresh, at this time we visit the /from request on each config-client, we can get the latest configuration information, and the configuration on each client has been loaded Configure content for the latest Svn
(curl -X POST http://IP:7002/bus/refresh)。
From the config-client console, we can see the following:
The RefreshListener listener class records the receipt of a remote refresh request and refreshes the log of the from attribute.
