With the recent official release of .NET Core 3, I think I will try an interesting little experiment. I like to use Electron to create web-based desktop applications. I want to learn more about Blazor (the newest member of the ASP.NET series). In this article, I will show you exactly how to start using Blazor and Electron in 15 minutes!

• .NET Core 3.0 SDK

• Node.js with npm

Make sure to install at the same time.NET Core SDK with Node.js(you can use it dotnet--versionwith node--versionCheck the version). We need .NET Core 3.0 because we will use dotnet new to build Blazor applications. We also need Electron.NET's .NET Core 3.0, which allows Electron and .NET integration. Node.js is used to download, configure and integrate with the actual Electron instance.

The installation procedure requires some simple steps. Although most of the steps are just commands, there are 2 files that need to be edited manually. After setting up the project, you only need one command to start it!

mkdir blazor-electron-demo
cd blazor-electron-demo
dotnet new blazorserver --no-https
dotnet add package ElectronNET.API
dotnet new tool-manifest
dotnet tool install ElectronNET.CLI
dotnet electronize init

Quite a few command blocks, but they are all simple and do not require any user interaction. Let's break down the role of each command:

mkdir blazor-electron-demo cd blazor-electron-demo	Create a folder for our project and set it as the current working directory. Make sure to change it to your preferred project name!
dotnetnewblazorserver--no-https	Created a new server-side Blazor application using the scaffolding template, which does not use HTTPs.
dotnet addpackageElectronNET.API	Install the NuGet package, which adds Electron support to ASP.NET applications.
dotnetnewtool-manifest	Added support for locally installed "dotnet" tools.
dotnet tool installElectronNET.CLI	Install the required ElectronNET.CLI locally in the project.
dotnet electronize init	Set up the Electron.NET manifest and update the startup configuration file.

All commands should be executed in order, one at a time. Once they are all done, you only need to change two files to run the application!

In order to integrate the ASP.NET application (in this case, the Blazor application) with Electron, we need toProgram.cswith Startup.csto modify. InProgram.csin:

using System;
using System.Collections.Generic;
using System.IO;
using System.Linq;
using System.Threading.Tasks;
using Microsoft.AspNetCore;
using Microsoft.AspNetCore.Hosting;
using Microsoft.Extensions.Configuration;
using Microsoft.Extensions.Hosting;
using Microsoft.Extensions.Logging;
using ElectronNET.API; // ADD THIS!
namespace blazor_electron_demo
{
    public class Program
    {
        public static void Main(string[] args)
        {
            CreateHostBuilder(args).Build().Run();
        }
        public static IHostBuilder CreateHostBuilder(string[] args) =>
            Host.CreateDefaultBuilder(args)
                .ConfigureWebHostDefaults(webBuilder =>
                {
                    webBuilder.UseStartup<Startup>()
                              .UseElectron(args);  // ADD THIS!
                });
    }
}

InStartup.csin:

using System;
using System.Collections.Generic;
using System.Linq;
using System.Threading.Tasks;
using Microsoft.AspNetCore.Builder;
using Microsoft.AspNetCore.Components;
using Microsoft.AspNetCore.Hosting;
using Microsoft.Extensions.Configuration;
using Microsoft.Extensions.DependencyInjection;
using Microsoft.Extensions.Hosting;
using blazor_electron_demo.Data;
using ElectronNET.API; // ADD THIS!
namespace blazor_electron_demo
{
    public class Startup
    {
        public Startup(IConfiguration configuration)
        {
            Configuration = configuration;
        }
        public IConfiguration Configuration { get; }
        public void ConfigureServices(IServiceCollection services)
        {
            services.AddRazorPages();
            services.AddServerSideBlazor();
            services.AddSingleton<WeatherForecastService>();
        }
        public void Configure(IApplicationBuilder app, IWebHostEnvironment env)
        {
            if (env.IsDevelopment()) {
                app.UseDeveloperExceptionPage();
            } else {
                app.UseExceptionHandler("/Error");
            }
            app.UseStaticFiles();
            app.UseRouting();
            app.UseEndpoints(endpoints =>
            {
                endpoints.MapBlazorHub();
                endpoints.MapFallbackToPage("/_Host");
            });
            // ADD THIS!
            Task.Run(async () => await Electron.WindowManager.CreateWindowAsync());
        }
    }
}

With the update of these two files, we can now run our application in Electron!

Our application can be run in two different ways. Through the command line or through the "Run" dialog of Visual Studio (through the startup configuration file added during the installation using dotnet electroize init).

dotnet electronize start

Blazor runs in a desktop application

After running, you can attach the debugger from Visual Studio's "Debug"> "Attach to Process..." and filter by project name.When running a .NET application, the breakpoint will work exactly as expected.You can even debug the code in Razor files!The only downside is that when you need to make changes, you must stop the application, edit the changes and restart it.We will discuss it later.

Thanks to Electron.NET, we can publish the application to the platform-specific installer with one command!

dotnet electronize build /target win
# OR
dotnet electronize build /target osx
# OR
dotnet electronize build /target linux

Windows Note: I did encounter an exceptionThegiven key'target'wasnotpresentinthe dictionary.Inmingw64When running a command at the prompt. Use this machinecmdOrpowershellTry the command again at the prompt.

This command will create a new installer in the ./bin/desktop folder. Inside, you will find an installer suitable for your platform!

I created a GitHub repository showing all the changes we just made. If you run into problems, please use it as a resource, or contact me on Twitter!

Although the combination of these two technologies is interesting, it does have its drawbacks. From developer workflow issues to API mismatches, these issues can be annoying, but when it comes to using Blazor and Electron, they are by no means a transaction barrier.

The most serious problem is the slow iterative development process. At this point, the developer's workflow includes starting the application, manually attaching the debugger, testing the application, then stopping the application to make changes and finally restarting the cycle. If there is no changed hot reload function, this will greatly increase the difficulty of development. The maintainers of Electron.NET recommend developing the application in a browser to accomplish most of the tasks and only switch to electronic for regular testing.

Electron.NET is very young, but fully functional. Creating a functional bridge from C# and .NET to JavaScript & Node.js/Electron is not easy. But you will most likely find unimplemented methods or events. Remember, Electron.NET is a free library that people create in their spare time. Every function may not exist, but this is where the brilliance of open source lies. If you find a bug in an API or function that requires some work, then please fork the project and try to find a fix yourself. Most of the time, building software is the result of collaboration, and it makes sense to help solve problems instead of just waiting to solve them.

We created a brand new Blazor project, added support for Electron with the help of Electron.NET, and created an installer ready to be released! Although there are indeed some warnings when using the development stack for this cutting-edge build, there are absolutely no warnings that prevent you from using Blazor to build incredible desktop applications. With the help of developers like you, Electron.NET will continue to improve!

Special thanks to Rob Horner and John Sedlak for helping to edit this article! Thank you Rob and John!

As always, if you like this article, please let me know on Twitter! If you have any questions or don’t know something, please let me know! I really appreciate your feedback!
