Earlier articles have introduced various scenarios for configuring the HTTP/2 protocol in Spring boot 2.0, but they are all introduced.h2protocol. There are two versions of the HTTP/2 protocol:h2 with h2c，h2c Yes h2 The plain text version is not based on TLS and has no security. It is precisely because there is no TLS layer encryption and decryption related steps, it is more suitable for communication between backend services, gRPC is to support both versions of the HTTP/2 protocol.

00 Foreword

An HTTP/2 connection is an application layer protocol built on top of a TCP connection, and the client is the initiator of a TCP connection.

HTTP/2 uses the same URI schemes as HTTP/1.1: "http" and "https", and still shares the same default port: http for 80, 443 for https. This means that the way "http" and "https" determine whether they support the HTTP/2 protocol is different.

inOfficial documentIn the definition, two versions are defined for the HTTP/2 protocol:h2 with h2c：

• The h2 version of the protocol is the HTTP/2 protocol built on top of the TLS layer. This flag is used in the TLS Application Layer Protocol Negotiation (TLS-ALPN) domain and any other HTTP/2 protocol over TLS.
• The h2c version is an HTTP/2 protocol built on plaintext TCP. This flag is used in the HTTP/1.1 upgrade protocol header field and any other HTTP/2 protocol directly above the TCP layer.

Since there are two versions in the official introduction of the HTTP/2 protocol, we havearticleIntroducing how Spring boot 2.0 is implementedh2, this article will introduce how to make Spring boot 2.0 supporth2cprotocol.

01 Spring boot 2.0 h2c protocol server

Since the h2c protocol is simpler than h2, it should not be difficult to implement, but from the official documentation of Spring boot 2.0, it clearly states that "Spring boot does not support h2c - the plain text version of the HTTP/2 protocol". So I would like other ways to support h2c.

First of all, the idea is to support h2c through the external tomcat configuration, because the server.xml configuration in tomcat8.5 has HTTP/2 protocol related configuration:

<Connector port="8443" protocol="org.apache.coyote.http11.Http11AprProtocol"
           maxThreads="150" SSLEnabled="true" >
    <UpgradeProtocol className="org.apache.coyote.http2.Http2Protocol" />
    <SSLHostConfig>
        <Certificate certificateKeyFile="conf/localhost-rsa-key.pem"
                     certificateFile="conf/localhost-rsa-cert.pem"
                     certificateChainFile="conf/localhost-rsa-chain.pem"
                     type="RSA" />
    </SSLHostConfig>
</Connector>

This shows that you want to add a certificate. The obvious support is based on the h2 version of the HTTP/2 protocol on the TLS layer, but you can disable SSL from the configuration, so I tried it and it succeeded. Configured as an example below, it supports h2c:

<Connector port="5080" protocol="HTTP/1.1" connectionTimeout="20000">
    <UpgradeProtocol className="org.apache.coyote.http2.Http2Protocol" />
</Connector>

The tomcat container itself supports multiple connectors configuration. I want to configure multiple connectors at the same time in Spring boot 2.0. See the official documentation of Spring boot and find the following configuration:

The example in the documentation is to configure a https connector via java configure. It is not supported in application.yaml to configure multiple connectors.

Therefore, I will imitate the way to configure h2c for external tomcat. In the built-in tomcat of Spring boot 2.0, configure h2c protocol through java configure. The specific code is as follows:

@Bean
public ServletWebServerFactory servletContainer() {
    TomcatServletWebServerFactory tomcat = new TomcatServletWebServerFactory();
    tomcat.addAdditionalTomcatConnectors(createH2cConnector());
    return tomcat;
}

private Connector createH2cConnector() {
    Connector connector = new Connector("org.apache.coyote.http11.Http11NioProtocol");
    Http2Protocol upgradeProtocol = new Http2Protocol();
    connector.addUpgradeProtocol(upgradeProtocol);
    //connector.setScheme("http");
    connector.setPort(5080);

    return connector;
}

At this point start our Spring boot application, we will find the last boot log, we start three ports at the same time, that is, three Connector:

Tomcat started on port(s): 8080 (http) 8443 (https) 5080 (http) with context path '/demo-h2c'

02 Curl tool to verify the h2c protocol server

First you need to check if your curl tool supports the HTTP/2 protocol.

➜  ~ curl -V
curl 7.54.0 (x86_64-apple-darwin17.0) libcurl/7.54.0 LibreSSL/2.0.20 zlib/1.2.11 nghttp2/1.24.0
Protocols: dict file ftp ftps gopher http https imap imaps ldap ldaps pop3 pop3s rtsp smb smbs smtp smtps telnet tftp
Features: AsynchDNS IPv6 Largefile GSS-API Kerberos SPNEGO NTLM NTLM_WB SSL libz HTTP2 UnixSockets HTTPS-proxy

From the Features information above, I found that my curl tool supports the HTTP/2 protocol.

Let's start by verifying that my Spring boot service is h2c on port 5080, as follows:

➜  ~ curl -v --http2 http://127.0.0.1:5080/demo-h2c/h2c/hello\?name\=guoyankui
*   Trying 127.0.0.1...
* TCP_NODELAY set
* Connected to 127.0.0.1 (127.0.0.1) port 5080 (#0)
> GET /demo-h2c/h2c/hello?name=guoyankui HTTP/1.1
> Host: 127.0.0.1:5080
> User-Agent: curl/7.54.0
> Accept: */*
> Connection: Upgrade, HTTP2-Settings
> Upgrade: h2c
> HTTP2-Settings: AAMAAABkAARAAAAAAAIAAAAA
>
< HTTP/1.1 101
< Connection: Upgrade
< Upgrade: h2c
< Date: Sun, 06 May 2018 13:12:37 GMT
* Received 101
* Using HTTP2, server supports multi-use
* Connection state changed (HTTP/2 confirmed)
* Copying HTTP/2 data in stream buffer to connection buffer after upgrade: len=0
* Connection state changed (MAX_CONCURRENT_STREAMS updated)!
< HTTP/2 200
< content-type: text/plain;charset=UTF-8
< date: Sun, 06 May 2018 13:12:37 GMT
<
* Connection #0 to host 127.0.0.1 left intact
Hello h2c: null%

OK, the verification passed.

03 java client supporting h2c protocol

In the previous section, we used the Curl tool to verify the h2c protocol for Spring boot 2.0 services, but in the Java language, we also need a Java client that supports h2c. At present, the general java client only supports h2, some do not support HTTP/2 protocol, and browsers generally do not support h2c.

Now it is not easy to find a java client that supports h2c. Currently find the latest version of okhttp3.3.10.0Does not support h2c, but found in the latest github code3.11.0-SNAPSHOTThe version is already supportedh2c, code example:

public static void main(String[] args) throws Exception {
    testH2C();
}

public static void testH2C() throws Exception {
    OkHttpClient okHttpClient = new OkHttpClient.Builder()
            .protocols(Arrays.asList(Protocol.H2C))
            .build();

    Request request = new Request.Builder()
            .url("http://127.0.0.1:5080/demo-h2c/h2c/hello?name=guoyankui")
            .build();
    Response response = okHttpClient.newCall(request).execute();
    System.out.println(response.protocol());
    System.out.println(response.body().string());
}

After executing this main function, the output is:

h2c
Hello h2c: guoyankui

From the output results, verifiedh2cThe client and server of the protocol.

04 End

Currently, I found okhttp33.11.0Version supporth2cThere is a Java client that supports h2c. We also implemented the h2c server in Spring boot 2.0, so we have support.h2cThe complete program of the agreement.
