SahderGraph achieve billboards

At this point: 2020.1.30
has a certain degree of knowledge of linear algebra + graphics. The attempt to achieve the billboard effect in the Shader Graph.

FIG left as default Shader. The right for the billboard effect, it will always face the camera.

principle:

By linear combination. We need to find a rotation matrix. This rotation matrix 3x3.
is a linear combination of three vectors are:

Apex pointing toward the camera (here taking the negative direction, because the normal direction triangle Quad Z-axis negative direction is the Quad.)
Cross product (vector 1 and the results of (0,1,0)) to give the right direction
Cross product (vector result 2,1) to give the direction.

Note here that Unity, a left-handed coordinate system.

practice:

On the way, due to the View Direction in Vertex stage "undeclared identifier (not identifiers)," so there needs its own calculation, and coordinate transformation.
