In developing the camera displays the camera preview data, sometimes the camera position is fixed, then we may need to use the correct image rotation, image rotation to obtain a certain angle we need. This article describes some of the common YUV, RGB data of the rotation method.

A, by rotating the image pixel

Consider the following one image:

Pixel1  Pixel2  Pixel3  Pixel4

Pixel5  Pixel6  Pixel7  Pixel8

Its image resolution iswidth x height

1. Rotate clockwise90After the degree, its contents will become:

Pixel5  Pixel1

Pixel6  Pixel2

Pixel7  Pixel3

Pixel8  Pixel4

Resolution becomesheight x width

That is:

• The first raw dataheight - 1 Line0 Pixel column will become the first target data0 Line0 Pixel columns
• The first raw dataheight - 1 Line1 Pixel column will become the first target data1 Line0 Pixel columns
• …
• The first raw dataheight - 1 Linewidth - 1 Pixel column will become the first target datawidth - 1 Line0 Pixel columns
• …
• The first raw data1 Linewidth - 1 Pixel column will become the first target datawidth - 1 Lineheight - 2 Pixel columns
• The first raw data1 Linewidth - 2 Pixel column will become the first target datawidth - 2 Lineheight - 2 Pixel columns
• The first raw data1 Linewidth - 3 Pixel column will become the first target datawidth - 3 Lineheight - 2 Pixel columns
• …
• The first raw datai Linej Pixel column will become the first target dataj Lineheight - 1 - i Pixel columns

2. ** 180 ** If the degree of rotation, the contents of which will become: > Pixel8 Pixel7 Pixel6 Pixel5
Pixel4  Pixel3  Pixel2  Pixel1

That is

• The first raw data0 Line0 Pixel column will become the first target dataheight - 1 Linewidth - 1 Pixel columns
• The first raw data1 Line0 Pixel column will become the first target dataheight - 2 Linewidth - 1 Pixel columns
• …
• The first raw dataheight - 1 Line0 Pixel column will become the first target data0 Linewidth - 1 Pixel columns
• The first raw dataheight - 1 Line1 Pixel column will become the first target data0 Linewidth - 2 Pixel columns
• …
• The first raw datai Linej Pixel column will become the first target dataheight - 1 - i Linewidth - 1 - j Pixel columns

3. ** 270 ** If the degree of rotation, the contents of which will become: > Pixel4 Pixel8
Pixel3  Pixel7
Pixel2  Pixel6
Pixel1  Pixel5

That is:

• The first raw data0 Linewidth - 1 Pixel column will become the first target data0 Line0 Pixel columns
• The first raw data0 Linewidth - 2 Pixel column will become the first target data1 Line0 Pixel columns
• …
• The first raw data0 Line0 Pixel column will become the first target datawidth - 1 Line0 Pixel columns
• …
• The first raw data1 Linewidth - 1 Pixel column will become the first target data0 Line1 Pixel columns
• The first raw data1 Linewidth - 2 Pixel column will become the first target data1 Line1 Pixel columns
• …
• The first raw datai Linej Pixel column will become the first target datawidth - j - 1 Linei Pixel columns

Second, rotating BGR24 / RGB24 data

BGR24 / RGB24 to 3 are byte as a pixel, and therefore need to be rotated as a whole byte 3 is rotated. Sample code is as follows.

• Rotate 90 degrees:

void rotateRgb24Degree90(char *rgb24, char *rotatedRgb24, int width, int height) {
    int lineDataSize = width * 3;
    int rotatedRgb24Index = 0;
    int finalLineStartIndex = (height - 1) * lineDataSize;
    for (int w = 0; w < lineDataSize; w += 3) {
        int bgr24StartIndex = finalLineStartIndex + w;
        int offset = 0;
        for (int h = 0; h < height; h++) {
            rotatedRgb24[rotatedRgb24Index++] = rgb24[bgr24StartIndex - offset];
            rotatedRgb24[rotatedRgb24Index++] = rgb24[bgr24StartIndex - offset + 1];
            rotatedRgb24[rotatedRgb24Index++] = rgb24[bgr24StartIndex - offset + 2];
            offset += lineDataSize;
        }
    }
}

• Rotated 180 degrees

void rotateRgb24Degree180(char *rgb24, char *rotatedRgb24, int width, int height) {
    int lineDataSize = width * 3;
    int rotatedRgb24Index = 0;
    int rgb24StartIndex = lineDataSize * height - 3;
    for (int h = height - 1; h >= 0; h--) {
        for (int w = lineDataSize - 3; w >= 0; w -= 3) {
            rotatedRgb24[rotatedRgb24Index++] = rgb24[rgb24StartIndex];
            rotatedRgb24[rotatedRgb24Index++] = rgb24[rgb24StartIndex + 1];
            rotatedRgb24[rotatedRgb24Index++] = rgb24[rgb24StartIndex + 2];
            rgb24StartIndex -= 3;
        }
    }
}

• Rotated 270 degrees

void rotateRgb24Degree270(char *rgb24, char *rotatedRgb24, int width, int height) {
    int lineDataSize = width * 3;
    int rotatedRgb24Index = 0;
    int finalColumnStartIndex = lineDataSize;
    for (int w = 0; w < lineDataSize; w += 3) {
        finalColumnStartIndex -= 3;
        int offset = 0;
        for (int h = 0; h < height; h++) {
            rotatedRgb24[rotatedRgb24Index++] = rgb24[finalColumnStartIndex + offset];
            rotatedRgb24[rotatedRgb24Index++] = rgb24[finalColumnStartIndex + offset + 1];
            rotatedRgb24[rotatedRgb24Index++] = rgb24[finalColumnStartIndex + offset + 2];
            offset += lineDataSize;
        }
    }
}

Third, the rotating NV21, NV12 data

For NV21 NV12 or data, which is arranged in a width * height Y consecutive memory, followed by the UV data height / 2 rows, each row is the UV data width / 2 and U-width / 2 V-interleaved (NV21 is VU VU VU VU ..., NV12 is UV UV UV UV ...), the size of the Y data happen to be the number of pixels, can be rotated directly, the U and V data, the need to consider the underlying hop case (because the U and V NV21 and NV12 of just the opposite position, the rotation of the code NV21 also apply to the rotation NV12). Sample code is as follows.

• Rotation90degree

void rotateNv21Degree90(char *nv21, char *rotatedNv21, int width, int height) {
    int yFinalLineStartIndex = (height - 1) * width;
    int rotatedYIndex = 0;
    //rotate y
    for (int w = 0; w < width; w++) {
        int yStartIndex = yFinalLineStartIndex + w;
        int offset = 0;
        for (int h = 0; h < height; h++) {
            rotatedNv21[rotatedYIndex++] = nv21[yStartIndex - offset];
            offset += width;
        }
    }
    //rotate uv
    int uvFinalLineStartIndex = width * height * 3 / 2 - width;
    int rotatedVIndex = width * height;
    int rotatedUIndex = width * height + 1;
    for (int w = 0; w < width; w += 2) {
        int uvStartIndex = uvFinalLineStartIndex + w;
        int offset = 0;
        for (int h = 0; h < height; h += 2) {
            rotatedNv21[rotatedVIndex] = nv21[uvStartIndex - offset];
            rotatedNv21[rotatedUIndex] = nv21[uvStartIndex - offset + 1];
            offset += width;
            rotatedVIndex += 2;
            rotatedUIndex += 2;
        }
    }
}

• Rotation180degree

void rotateNv21Degree180(char *nv21, char *rotatedNv21, int width, int height) {
    int yIndex = width * height - 1;
    int rotatedYIndex = 0;
    //rotate y
    for (int h = height - 1; h >= 0; h--) {
        for (int w = width - 1; w >= 0; w--) {
            rotatedNv21[rotatedYIndex++] = nv21[yIndex];
            yIndex--;
        }
    }
    int uvIndex = width * height * 3 / 2 - 2;
    int rotatedVIndex = width * height;
    int rotatedUIndex = width * height + 1;
    //rotate uv
    for (int h = height - 1; h >= 0; h -= 2) {
        for (int w = width - 1; w >= 0; w -= 2) {
            rotatedNv21[rotatedVIndex] = nv21[uvIndex];
            rotatedNv21[rotatedUIndex] = nv21[uvIndex + 1];
            uvIndex -= 2;
            rotatedVIndex += 2;
            rotatedUIndex += 2;
        }
    }
}

• Rotation270degree

void rotateNv21Degree270(char *nv21, char *rotatedNv21, int width, int height) {
    int rotatedYIndex = 0;
    int yFinalColumnStartIndex = width;
    //rotate y
    for (int w = 0; w < width; w++) {
        int offset = 0;
        for (int h = 0; h < height; h++) {
            rotatedNv21[rotatedYIndex++] = nv21[yFinalColumnStartIndex + offset];
            offset += width;
        }
        yFinalColumnStartIndex--;
    }
    //rotate uv
    int uvFinalColumnStartIndex = width * height + width;
    int rotatedVIndex = width * height;
    int rotatedUIndex = width * height + 1;
    for (int w = 0; w < width; w += 2) {
        uvFinalColumnStartIndex -= 2;
        int offset = 0;
        for (int h = 0; h < height; h += 2) {
            rotatedNv21[rotatedVIndex] = nv21[uvFinalColumnStartIndex + offset];
            rotatedNv21[rotatedUIndex] = nv21[uvFinalColumnStartIndex + offset + 1];
            offset += width;
            rotatedVIndex += 2;
            rotatedUIndex += 2;
        }
    }
}

Fourth, the rotation I420, YV12 data

For I420, YV12 data, which is arranged in a width * height Y consecutive memory, followed by a continuous U and V or V and continuous U (I420 is UUUUUUUU ... VVVVVVVV ..., YV12 is VVVVVVVV ... UUUUUUUU ...), Y data just the right size is the number of pixels, can be rotated directly; for width and height are only half the width and height of the Y, U and V, so that each half (since I420 and YV12 U and V but just the position Y of the width and height of the number of cycles Instead, the code I420 rotation also apply to the rotation YV12). Sample code is as follows.

• Rotation90degree

void rotateI420Degree90(char *i420, char *rotatedI420, int width, int height) {
    int halfWidth = width / 2;
    int yFinalLineStartIndex = (height - 1) * width;
    int rotatedYIndex = 0;
    //rotate y
    for (int w = 0; w < width; w++) {
        int yStartIndex = yFinalLineStartIndex + w;
        int offset = 0;
        for (int h = 0; h < height; h++) {
            rotatedI420[rotatedYIndex++] = i420[yStartIndex - offset];
            offset += width;
        }
    }
    //rotate uv
    int uFinalLineStartIndex = width * height * 5 / 4 - halfWidth;
    int vFinalLineStartIndex = width * height * 3 / 2 - halfWidth;
    int rotatedUIndex = width * height;
    int rotatedVIndex = width * height * 5 / 4;
    for (int w = 0; w < width; w += 2) {
        int uStartIndex = uFinalLineStartIndex + w / 2;
        int vStartIndex = vFinalLineStartIndex + w / 2;
        int offset = 0;
        for (int h = 0; h < height; h += 2) {
            rotatedI420[rotatedUIndex++] = i420[uStartIndex - offset];
            rotatedI420[rotatedVIndex++] = i420[vStartIndex - offset];
            offset += halfWidth;
        }
    }
}

• Rotation180degree

void rotateI420Degree180(char *i420, char *rotatedI420, int width, int height) {
    int yIndex = width * height - 1;
    int rotatedYIndex = 0;
    //rotate y
    for (int h = height - 1; h >= 0; h--) {
        for (int w = width - 1; w >= 0; w--) {
            rotatedI420[rotatedYIndex++] = i420[yIndex];
            yIndex--;
        }
    }
    int uIndex = width * height * 5 / 4 - 1;
    int vIndex = width * height * 3 / 2 - 1;
    int rotatedUIndex = width * height;
    int rotatedVIndex = width * height * 5 / 4;
    //rotate uv
    for (int h = height - 1; h >= 0; h -= 2) {
        for (int w = width - 1; w >= 0; w -= 2) {
            rotatedI420[rotatedUIndex++] = i420[uIndex--];
            rotatedI420[rotatedVIndex++] = i420[vIndex--];
        }
    }
}

• Rotation270degree

void rotateI420Degree270(char *i420, char *rotatedI420, int width, int height) {
    int halfWidth = width / 2;
    int yFinalColumnStartIndex = width;
    int rotatedYIndex = 0;
    //rotate y
    for (int w = 0; w < width; w++) {
        int offset = 0;
        for (int h = 0; h < height; h++) {
            rotatedI420[rotatedYIndex++] = i420[yFinalColumnStartIndex + offset];
            offset += width;
        }
        yFinalColumnStartIndex--;
    }
    //rotate uv
    int uFinalColumnStartIndex = width * height + width;
    int vFinalColumnStartIndex = width * height * 5 / 4 + width;
    int rotatedUIndex = width * height;
    int rotatedVIndex = width * height * 5 / 4;
    for (int w = 0; w < width; w += 2) {
        uFinalColumnStartIndex--;
        vFinalColumnStartIndex--;
        int offset = 0;
        for (int h = 0; h < height; h += 2) {
            rotatedI420[rotatedUIndex++] = i420[uFinalColumnStartIndex + offset];
            rotatedI420[rotatedVIndex++] = i420[vFinalColumnStartIndex + offset];
            offset += halfWidth;
        }
    }
}

Fifth, the rotation YUYV data

Since the arrangement is YUYV (YUYV YUYV YUYV ...), each of which is a common relationship between two laterally adjacent Y uses the same set of U and V, and therefore, when rotated by 180 degrees, the common relationship may not be broken YUV, change the order of only two of every four byte Y; however when rotated 90 degrees or 270 degrees, since the original transverse Y will be modified as a common longitudinal relationship, YUV will also be broken. Sample code is as follows.

• Rotation90degree

void rotateYuyvDegree90(char *yuyv, char *rotatedYuyv, int width, int height) {
    int lineDataSize = width * 2;
    int rotatedLineDataSize = height * 2;
    int rotatedYuyvIndex = 0;
    int finalLineStartIndex = (height - 1) * lineDataSize;
    for (int w = 0; w < lineDataSize; w += 4) {
        int yuyvStartIndex = finalLineStartIndex + w;
        int offset = 0;
        for (int h = 0; h < height; h += 2) {
            /**
             * y1 u1 y2 v2   y3 u2 y4 v2
                           * - Brain Screen> rotated to make up
             * y5 u3 y6 v3   y7 u4 y8 v4
             */
            //y5
            rotatedYuyv[rotatedYuyvIndex] = yuyv[yuyvStartIndex - offset + lineDataSize];
            //u3
            rotatedYuyv[rotatedYuyvIndex + 1] = yuyv[yuyvStartIndex - offset + lineDataSize + 1];
            //y1
            rotatedYuyv[rotatedYuyvIndex + 2] = yuyv[yuyvStartIndex - offset];
            //v3
            rotatedYuyv[rotatedYuyvIndex + 3] = yuyv[yuyvStartIndex - offset + lineDataSize + 3];

            //y6
            rotatedYuyv[rotatedYuyvIndex + rotatedLineDataSize] = yuyv[yuyvStartIndex + lineDataSize - offset + 2];
            //u1
            rotatedYuyv[rotatedYuyvIndex + rotatedLineDataSize + 1] = yuyv[yuyvStartIndex - offset + 1];
            //y2
            rotatedYuyv[rotatedYuyvIndex + rotatedLineDataSize + 2] = yuyv[yuyvStartIndex - offset + 2];
            //v1
            rotatedYuyv[rotatedYuyvIndex + rotatedLineDataSize + 3] = yuyv[yuyvStartIndex - offset + 3];

            rotatedYuyvIndex += 4;
            offset += lineDataSize * 2;
        }
        rotatedYuyvIndex += rotatedLineDataSize;
    }
}

• Rotation180degree

void rotateYuyvDegree180(char *yuyv, char *rotatedYuyv, int width, int height) {
    int lineDataSize = width * 2;
    int yuyvIndex = lineDataSize * height - 4;
    int rotatedIndex = 0;
    //rotate
    for (int h = height - 1; h >= 0; h--) {
        for (int w = lineDataSize - 4; w >= 0; w -= 4) {
            rotatedYuyv[rotatedIndex++] = yuyv[yuyvIndex + 2];
            rotatedYuyv[rotatedIndex++] = yuyv[yuyvIndex + 1];
            rotatedYuyv[rotatedIndex++] = yuyv[yuyvIndex];
            rotatedYuyv[rotatedIndex++] = yuyv[yuyvIndex + 3];
            yuyvIndex -= 4;
        }
    }
}

• Rotation270degree

void rotateYuyvDegree270(char *yuyv, char *rotatedYuyv, int width, int height) {
    int lineDataSize = width * 2;
    int rotatedLineDataSize = height * 2;
    int rotatedYuyvIndex = 0;
    int finalColumnStartIndex = lineDataSize - 4;
    for (int w = 0; w < lineDataSize; w += 4) {
        int offset = 0;
        for (int h = 0; h < height; h += 2) {
            /**
             * y1 u1 y2 v1   y3 u2 y4 v2
             * - Brain Screen> rotated to make up
             * y5 u3 y6 v3   y7 u4 y8 v4
             */

            //y4
            rotatedYuyv[rotatedYuyvIndex] = yuyv[finalColumnStartIndex + offset + 2];
            //u2
            rotatedYuyv[rotatedYuyvIndex + 1] = yuyv[finalColumnStartIndex + offset + 1];
            //y8
            rotatedYuyv[rotatedYuyvIndex + 2] = yuyv[finalColumnStartIndex + offset + lineDataSize +
                                                     2];
            //v2
            rotatedYuyv[rotatedYuyvIndex + 3] = yuyv[finalColumnStartIndex + offset + 3];

            //y3
            rotatedYuyv[rotatedYuyvIndex + rotatedLineDataSize] = yuyv[finalColumnStartIndex + offset];
            //u4
            rotatedYuyv[rotatedYuyvIndex + rotatedLineDataSize + 1] = yuyv[finalColumnStartIndex + lineDataSize + offset + 1];
            //y7
            rotatedYuyv[rotatedYuyvIndex + rotatedLineDataSize + 2] = yuyv[finalColumnStartIndex + lineDataSize + offset];
            //v4
            rotatedYuyv[rotatedYuyvIndex + rotatedLineDataSize + 3] = yuyv[finalColumnStartIndex + lineDataSize + offset + 3];

            rotatedYuyvIndex += 4;
            offset += lineDataSize * 2;
        }
        finalColumnStartIndex -= 4;
        rotatedYuyvIndex += rotatedLineDataSize;
    }
}
