Blog Park original link:[tf.keras] tf.keras loading AlexNet pre-training model – wuliytTaotao。

The pre-training models for tf.keras are placed in the 'tensorflow.python.keras.applications' directory. In the tensorflow 1.10 release, the pre-trained models are:

DenseNet121, DenseNet169, DenseNet201, InceptionResNetV2, InceptionV3, MobileNet, NASNetLarge, NASNetMobile, ResNet50, VGG16, VGG19, Xception.

Looking for a long time, I found that keras did not have pre-trained AlexNet. . .

So this article provides a way to import pre-training models from other frameworks (such as PyTorch). Let's take AlexNet as an example.

Export model parameters from PyTorch

First of all, understand that when the structure of the model is the same, we only need to import the parameters of the model to reproduce the model, so we have to export the pre-trained model parameters from PyTorch and load them with keras.

Here is a Microsoft project:MMdnn. MMdnn allows us to convert models between different depth learning frameworks. Here I also use MMdnn to convert AlexNet(PyTorch to Keras).

Step 0: Configure the environment

Must be configured consistently:
 - PyTorch: 0.4.0 (If there is a problem with other versions, please return to version 0.4.0)

 Not necessarily consistently configured:
- numpy: 1.14.5
 - Keras: 2.1.3 (not keras in tensorflow)

Step 1: Install MMdnn

$ pip3 install mmdnn

The mmdnn version I installed is 0.2.5.

For other installation methods, please refer togithub。

Step 2: Get a model (pth file) where PyTorch saves the complete structure and parameters

When PyTorch saves the model, you can save the entire model, or you can save only the parameters of the model, which are stored in the pth file.

The pth file of the mmdnn operation is required to contain the model structure.FAQ, while pre-training in PyTorch AlexNet only saved the parameters.

The AlexNet pre-training model (pth file) containing the model structure and weights is obtained by the following procedure:

import torch
import torchvision

m = torchvision.models.alexnet(pretrained=True)
torch.save(m, './alexnet.pth')

For other models, such as resnet101, a pre-trained model with structure and weight can be obtained directly by the following instructions:

$ mmdownload -f pytorch -n resnet101 -o ./

(Do not get alexnet.pth through the above instructions, because it only contains weights, but no structure, so there will be an error in the next step "AttributeError: ‘collections.OrderedDict' object has no attribute ‘state_dict’”.)

Step 3: Export the parameters of the PyTorch model and save to the hdf5 file

Execute the following three instructions in turn, and finally get a ‘keras_alexnet.h5’ file, which is the pre-training weight file we want keras to load.

$ mmtoir -f pytorch -d alexnet --inputShape 3,227,227 -n alexnet.pth
IR network structure is saved as [alexnet.json].
IR network structure is saved as [alexnet.pb].
IR weights are saved as [alexnet.npy].
$ mmtocode -f keras --IRModelPath alexnet.pb --IRWeightPath alexnet.npy --dstModelPath keras_alexnet.py
Using TensorFlow backend.
Parse file [alexnet.pb] with binary format successfully.
Target network code snippet is saved as [keras_alexnet.py].
$ python3 -m mmdnn.conversion.examples.keras.imagenet_test -n keras_alexnet.py -w alexnet.npy --dump keras_alexnet.h5
Using TensorFlow backend.
Keras model file is saved as [keras_alexnet.h5], generated by [keras_alexnet.py.py] and [alexnet.npy].

Possible problems

• AttributeError: ‘Conv2d’ object has no attribute ‘padding_mode’

Solution: PyTorch version problem, this problem will occur in version 1.1.0, and you can fall back to version 0.4.0.

$ pip install -i https://pypi.tuna.tsinghua.edu.cn/simple --upgrade torch==0.4.0 torchvision==0.2.0

• ValueError: Object arrays cannot be loaded when allow_pickle=False

Solution: Please change the numpy version.

• AttributeError: ‘collections.OrderedDict’ object has no attribute ‘state_dict’

The Solution:pth file contains only model parameters and no model structure, load it in PyTorch and save the pth file containing the model structure and parameters.

Verify the AlexNet pre-training model exported from PyTorch

Several images, code, and generated keras_alexnet.h5 files for testing were stored.wuliytTaotao · Github。

import torch
import torchvision
import cv2
import numpy as np

from torch.autograd import Variable

import tensorflow as tf
from tensorflow.keras import layers,regularizers


filename_test = 'data/dog2.png'

img = cv2.imread(filename_test)
img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)

#
img = cv2.resize(img, (227, 227))
img = img / 255.0
img = np.reshape(img, (1, 227, 227, 3))
# ,This is the pre-processing method for the PyTorch pre-trained AlexNet model. See https://pytorch.org/docs/stable/torchvision/models.html for details.
mean = np.array([0.485, 0.456, 0.406]).reshape([1, 1, 1, 3])
std = np.array([0.229, 0.224, 0.225]).reshape([1, 1, 1, 3])
img = (img - mean) / std

# PyTorch
# PyTorch Data input channel arrangement is inconsistent with Keras
img_tmp = np.transpose(img, (0, 3, 1, 2))

model = torchvision.models.alexnet(pretrained=True)

# torch.save(model, './model/alexnet.pth')
model = model.double()
model.eval()

y = model(Variable(torch.tensor(img_tmp)))
# Forecasted category
print(np.argmax(y.detach().numpy()))


# Keras
def get_AlexNet(num_classes=1000, drop_rate=0.5, regularizer_rate=0.01):
    """
         The AlexNet pre-training model structure implemented in PyTorch has a depth of (64, 192, 384, 256, 256).
         Returns the inputs and outputs of AlexNet
    """
    inputs = layers.Input(shape=[227, 227, 3])

    conv1 = layers.Conv2D(64, (11, 11), strides=(4, 4), padding='valid', activation='relu')(inputs)

    pool1 = layers.MaxPooling2D(pool_size=(3, 3), strides=(2, 2))(conv1)

    conv2 = layers.Conv2D(192, (5, 5), strides=(1, 1), padding='same', activation='relu')(pool1)

    pool2 = layers.MaxPooling2D(pool_size=(3, 3), strides=(2, 2))(conv2)

    conv3 = layers.Conv2D(384, (3, 3), strides=(1, 1), padding='same', activation='relu')(pool2)

    conv4 = layers.Conv2D(256, (3, 3), strides=(1, 1), padding='same', activation='relu')(conv3)

    conv5 = layers.Conv2D(256, (3, 3), strides=(1, 1), padding='same', activation='relu')(conv4)

    pool3 = layers.MaxPooling2D(pool_size=(3, 3), strides=(2, 2))(conv5)

    flat = layers.Flatten()(pool3)

    dense1 = layers.Dense(4096, activation='relu', kernel_regularizer=regularizers.l2(regularizer_rate))(flat)
    dense1 = layers.Dropout(drop_rate)(dense1)
    dense2 = layers.Dense(4096, activation='relu', kernel_regularizer=regularizers.l2(regularizer_rate))(dense1)
    dense2 = layers.Dropout(drop_rate)(dense2)
    outputs = layers.Dense(num_classes, activation='softmax', kernel_regularizer=regularizers.l2(regularizer_rate))(dense2)

    return inputs, outputs

inputs, outputs = get_AlexNet()
model2 = tf.keras.Model(inputs, outputs)
model2.load_weights('./keras_alexnet.h5')
# Forecasted category
print(np.argmax(model2.predict(img)))

Please refer to the blog for the categories represented by the forecast results.ImageNet Image Library 1000 category names (Chinese comments are constantly updated)。

Attentions

Pre-training in PyTorch The number of AlexNet model convolutional layers is inconsistent with the original paper, and the number of filters is different. $64，192，384，256，256$64，192，384，256，256. See specificGitHub - pytorch: vision/torchvision/models/alexnet.py

The explanation given by PyTorch is that its pre-training AlexNet model uses papers.Krizhevsky, A. (2014). One weird trick for parallelizing convolutional neural networks. arXiv preprint arXiv:1404.5997. The architecture given, but PyTorch's model architecture is different from this paper. The fourth convolutional filter in this paper is 384 and PyTorch is 256.

The AlexNet implemented in caffe contains the original LRN layer. After removing the LRN layer, the individual feels that the pre-training weight cannot be used directly.
