If you want to display data arranged in the table, you can use qtableWidget to display without having to handle too much configuration.

Note that using QTableWidget is not the only path to display information in the table. You can also create a data model and use QTableView to display it, but this is not within the scope of this tutorial.



note

This widget is an outstanding version you can further customize. To learn more about model / view architecture in QT, see its official documentation.

1. Import qtableWidget, QTableWidgetItem and QColor to display background colors:

import sys
from PySide6.QtGui import QColor
from PySide6.QtWidgets import (QApplication, QTableWidget,
                               QTableWidgetItem)

2. Create a simple data model that contains the names and hexadecimal code lists of different colors:

colors = [("Red", "#FF0000"),
          ("Green", "#00FF00"),
          ("Blue", "#0000FF"),
          ("Black", "#000000"),
          ("White", "#FFFFFF"),
          ("Electric Green", "#41CD52"),
          ("Dark Blue", "#222840"),
          ("Yellow", "#F9E56d")]

3, define a function, convert the hexadecimal code into an equivalent RGB:

def get_rgb_from_hex(code):
    code_hex = code.replace("#", "")
    rgb = tuple(int(code_hex[i:i+2], 16) for i in (0, 2, 4))
    return QColor.fromRgb(rgb[0], rgb[1], rgb[2])

4, initialize QAPPlication Some case:

app = QApplication()

5. Configure the QTableWidget to have the number of rows equal to the number of items in the Colors structure, and the number of columns with a color entry, plus one. You can set the column name using SethorizontalHeaderLabels, as described below:

table = QTableWidget()
table.setRowCount(len(colors))
table.setColumnCount(len(colors[0]) + 1)
table.setHorizontalHeaderLabels(["Name", "Hex Code", "Color"])

note

The reason for using +1 is to include a new column, we can display colors in it.

6, iterative data structure, create a QTableWidgetItems instance, and use X, Y coordinates to add them to the table. Here, the data is allocated:

for i, (name, code) in enumerate(colors):
    item_name = QTableWidgetItem(name)
    item_code = QTableWidgetItem(code)
    item_color = QTableWidgetItem()
    item_color.setBackground(get_rgb_from_hex(code))
    table.setItem(i, 0, item_name)
    table.setItem(i, 1, item_code)
    table.setItem(i, 2, item_color)

7. Display the table and execute QApplication.

table.show()
sys.exit(app.exec())

The final application is as follows:



Test code:

# This Python file uses the following encoding: utf-8
import sys
from PySide6.QtGui import QColor
from PySide6.QtWidgets import (QApplication, QWidget, QTableWidget,
                               QTableWidgetItem, QVBoxLayout)

colors = [("Red", "#FF0000"),
          ("Green", "#00FF00"),
          ("Blue", "#0000FF"),
          ("Black", "#000000"),
          ("White", "#FFFFFF"),
          ("Electric Green", "#41CD52"),
          ("Dark Blue", "#222840"),
          ("Yellow", "#F9E56d")]


def get_rgb_from_hex(code):
    code_hex = code.replace("#", "")
    rgb = tuple(int(code_hex[i:i+2], 16) for i in (0, 2, 4))
    return QColor.fromRgb(rgb[0], rgb[1], rgb[2])


class tableData(QWidget):
    def __init__(self, parent=None):
        super(tableData, self).__init__(parent)
        self.setWindowTitle("My TableData")

        self.table = QTableWidget()
        self.table.setRowCount(len(colors))
        self.table.setColumnCount(len(colors[0]) + 1)
        self.table.setHorizontalHeaderLabels(["Name", "Hex Code", "Color"])

        for i, (name, code) in enumerate(colors):
            item_name = QTableWidgetItem(name)
            item_code = QTableWidgetItem(code)
            item_color = QTableWidgetItem()
            item_color.setBackground(get_rgb_from_hex(code))
            self.table.setItem(i, 0, item_name)
            self.table.setItem(i, 1, item_code)
            self.table.setItem(i, 2, item_color)

        layout = QVBoxLayout(self)
        layout.addWidget(self.table)


if __name__ == "__main__":
    app = QApplication([])
    window = tableData()
    window.show()
    sys.exit(app.exec())



test results:
